2396761 Cembre CL3/0-D141 COLOUR CODED TERMINAL
MPN: 2396761
Alt. SKU: CL3/0-D141
Special Price
£6.79
£5.66
Regular Price
£8.50
2396761 Cembre CL3/0-D141 COLOUR CODED TERMINAL is available to buy in increments of 30
Cembre CL3/0-D141 Copper Cable Lug - 95mm² - M6 Stud
The Cembre CL3/0-D141 is a high-quality, tin-plated copper cable lug designed for secure and reliable crimping of 95mm² conductors onto M6 studs. Compliant with UL 486A-486B, this lug ensures dependable performance in demanding electrical applications.
Why Choose the Cembre CL3/0-D141?
This cable lug offers a combination of robust construction, precise engineering, and compliance with international standards, providing a secure and long-lasting connection for your critical applications. Easy insertion and clear markings simplify installation and reduce errors.
Key Features
- UL 486A-486B compliant for assured safety and performance.
- Tin-plated electrolytic copper construction for excellent conductivity and corrosion resistance.
- 95mm² conductor capacity for high-current applications.
- M6 stud size for compatibility with standard electrical equipment.
- Color-coded and clearly marked for easy identification and traceability.
- Easy insertion design for efficient installation.
Technical Specifications
- Part Number: 2396761
- Cable Cross Section: 95 mm²
- Stud Size: M6
- Operating Temperature: -50°C to +150°C
- Maximum Operating Voltage: 35kV
- Material: Electrolytic copper with >99.95% purity, tin-plated
- Dimensions (L x W x H): 82mm x 36mm x 8mm
- Die Index: 16 (Orange)
- Customs Code: 85369010
- ETIM Class: EC001051
Applications
- Industrial control panels
- Power distribution systems
- Motor control centers
- High-current electrical installations
- Maintenance and repair operations
Frequently Asked Questions
What makes this product special?
This product meets stringent UL 486A-486B compliance standards and is manufactured from high-purity, tin-plated electrolytic copper for exceptional performance and longevity.
What tools are required for installation?
A Cembre crimping tool compatible with die index 16 (Orange) is recommended for optimal crimping performance and reliable connections.
Is it suitable for aluminum conductors?
No, this cable lug is specifically designed for use with copper conductors. Using it with aluminum conductors could lead to connection failure.
| Manufacturer | Cembre |
|---|---|
| Manufacturer Part Number | 2396761 |
| Colour | Orange |
| Country of Manufacture | Italy |
| HS Code | 85369010 |
| Alternative Product SKU | CL3/0-D141 |
| Barcode | 8016692811666 |
| Packed Quantity | 30 |
