22.34.0.024.1740 Finder contactor 4 pole 25A AC/DC 24V 3NO 1NC

Why Choose the Finder 22.34.0.024.1740 Modular Contactor?

The Finder 22.34.0.024.1740 is a dependable and compact modular installation contactor designed for switching electrical loads in industrial automation, commercial buildings and modern electrical distribution systems. As part of the highly regarded Finder 22 Series, this modular contactor provides reliable switching performance, low-noise operation and efficient DIN rail mounting for demanding applications.

Equipped with a 24 V AC/DC control coil and a 3 normally open plus 1 normally closed contact configuration, the Finder 22.34.0.024.1740 is ideal for lighting systems, HVAC equipment, pumps, automation panels and motor control circuits. Its AgNi contact material offers dependable switching capability for resistive, moderately inductive and motor loads.

The contactor also includes practical integrated features such as a mechanical contact position indicator, front-mounted LED indication and an Auto-On-Off selector switch for simplified testing, maintenance and commissioning. Its compact 35 mm modular housing enables efficient use of panel space while maintaining high operational reliability.

Key Advantages

• Compact modular contactor for DIN rail installation.
• 25 A switching capacity for industrial and commercial applications.
• 3 NO + 1 NC contact arrangement for flexible switching control.
• 24 V AC/DC silent coil suitable for automation systems.
• Integrated LED and mechanical switching indication.
• Manual Auto-On-Off selector switch for testing and servicing.
• AgNi contact material suitable for resistive and motor loads.

Key Features

• Finder 22 Series modular installation contactor.
• 25 A rated operational current.
• 3 NO + 1 NC contact configuration.
• 24 V AC/DC control voltage.
• 35 mm DIN rail mounting according to EN 60715.
• Integrated LED operational indication.
• Mechanical contact position indicator.
• Auto-On-Off selector switch for manual operation.
• Silent AC/DC coil with integrated protection varistor.
• Designed for continuous duty operation.

Technical Specifications

• Manufacturer: Finder
• Series: 22 Series
• Model: 22.34.0.024.1740
• Product type: Modular installation contactor
• Rated operational current: 25 A
• Contact configuration: 3 NO + 1 NC
• Control voltage: 24 V AC/DC
• Rated operational voltage: 250–440 V AC
• Contact material: AgNi
• Mounting type: DIN rail mounting
• Protection rating: IP20
• Housing width: 35 mm
• Height: 88.8 mm
• Depth: approx. 60.8 mm
• Operating temperature: approximately -25°C to +50°C
• Standards: EN 61095 compliant

Reliable Switching for Building and Automation Systems

Finder modular contactors are designed for efficient switching of electrical loads within industrial and commercial systems. Their compact dimensions, silent operation and dependable contact performance make them ideal for use in automation panels, electrical distribution boards and building management systems.

The Finder 22.34.0.024.1740 combines reliable long-term switching performance with practical maintenance functions that simplify installation, diagnostics and operational management for electricians and automation engineers.

Typical Applications

• Lighting and building automation systems.
• HVAC and ventilation equipment.
• Industrial automation and machinery control.
• Pump and motor switching applications.
• Commercial electrical distribution systems.
• Energy management and smart building installations.

Trusted by Electricians and Automation Engineers Worldwide

Finder modular contactors are trusted across industrial automation and commercial electrical installations for their dependable switching performance, compact design and reliable long-term operation.
