1sna400782r0000 - hd6/22,f12g

Why Choose Control Panel Accessories?

High-quality accessories help maintain safety, improve installation efficiency, and ensure long-term reliability in electrical panels.

Integration

Designed for use in electrical panels and automation systems where reliability and modularity are essential.

What Customers Say

“Reliable quality and easy installation - a must-have in every panel we build.” - Panel Assembly Lead

Key Features

• Industrial-grade durability
• Consistent and safe operation
• Optimised for control panel use
• Compatible with common DIN rail configurations

Comparison with Similar Products

This product offers better performance, ease of use, and reliability compared to general-purpose alternatives.

Technical Specifications

• Block function: Feed-Through
• Product type: Stud Terminal Block
• Colour: Beige
• Pitch: 22 mm [ .866 in ]
• Number of positions: 13
• Number of Circuits :: 1
• Number of Levels :: 1
• Current Rating (NF F 61-017) (A):: 115 | 16
• Voltage Rating (NF F 61-017) (VAC):: 400
• Voltage Rating (NF F 61-017) (VDC):: 500
• Operating Voltage (VAC):: 600
• Product Weight :: 55 g [ 1.94 oz ]
• Contact Current Rating (Max) (A):: 115
• Termination Method to Wire & Cable :: Quick Connect | Screw Terminal
• Tightening Torque (in-lbs):: 46.9
• Tightening Torque (Nm):: 5.3
• Mounting: DIN Rail
• Housing material: Polyamide
• Product Height :: 50 mm [ 1.968 in ]
• Product Length :: 46.2 mm [ 1.818 in ]
• Product Depth :: 46.2 mm [ 1.818 in ]
• Product Width :: 22 mm [ .866 in ]
• Wire Size (NFC) (mm²):: 35
• Wire Size (AWG):: 10
• Wire Size (mm²):: 35
• Operating temperature range: -55 - 110 °C [ -67 - 230 °F ]
