1sna162979r0700 - block 14h 2t5 with screen
MPN: 1SNA162979R0700
Alt. SKU: BLOCK 14H 2T5 WITH SCREEN
Special Price
£7.08
£5.90
Regular Price
£11.80
1sna162979r0700 - block 14h 2t5 with screen is available to buy in increments of 25
Why Choose Control Panel Accessories?
High-quality accessories help maintain safety, improve installation efficiency, and ensure long-term reliability in electrical panels.
Integration
Designed for use in electrical panels and automation systems where reliability and modularity are essential.
What Customers Say
“Reliable quality and easy installation - a must-have in every panel we build.” - Panel Assembly Lead
Key Features
- Industrial-grade durability
- Consistent and safe operation
- Optimised for control panel use
- Compatible with common DIN rail configurations
Comparison with Similar Products
This product offers better performance, ease of use, and reliability compared to general-purpose alternatives.
Technical Specifications
- Block function: Feed-Through
- Product type: Stud Terminal Block
- Colour: Beige
- Pitch: 14 mm [ .551 in ]
- Number of positions: 2
- Number of Levels :: 1
- Current Rating (DIN) (A):: 65
- Current Rating (NF F 61-017) (A):: 51
- Voltage Rating (NFC) (VAC):: 500
- Voltage Rating (NFC) (VDC):: 500
- Voltage Rating (NF F 61-017) (VAC):: 380
- Voltage Rating (NF F 61-017) (VDC):: 500
- Voltage Rating (DIN) (VAC):: 500
- Voltage Rating (DIN) (V):: 600
- Current Rating (NFC) (A):: 71
- Operating Voltage (VAC):: 600
- Product Weight :: 27 g [ .952 oz ]
- Contact Current Rating (Max) (A):: 71
- Termination Method to Wire & Cable :: Screw Terminal
- Tightening Torque (in-lbs):: 22.1
- Tightening Torque (Nm):: 2.5
- Mounting: DIN Rail
- Housing material: Polyamide
- Product Height :: 54 mm [ 2.125 in ]
- Product Length :: 36 mm [ 1.417 in ]
- Product Depth :: 36 mm [ 1.417 in ]
- Product Width :: 14 mm [ .551 in ]
- Wire Size (NFC) (mm²):: 16
- Wire Size (AWG):: 16
- Wire Size (mm²):: 6
- Operating temperature range: -55 - 110 °C [ -67 - 230 °F ]
- UL Flammability Rating :: UL 94V-0
Frequently Asked Questions
What is the terminal spacing?
The pitch between terminals is 14 mm [ .551 in ].
How is the terminal block mounted?
It is designed for DIN Rail mounting.
| Manufacturer Part Number | 1SNA162979R0700 |
|---|---|
| Height | 54mm |
| Width | 14mm |
| Depth | 36mm |
| Manufacturer | Entrelec |
| Packed Quantity | 25 |
| Barcode | 3472591629798 |
| Alternative Product SKU | BLOCK 14H 2T5 WITH SCREEN |
