1SFL427102R1311 af116-40-11b-13 55kw/116 amp 100-250v 50/60hz dc ABB Contactor
MPN: 1SFL427102R1311
Alt. SKU: AF116-40-11B-13
Special Price
£361.96
£301.63
Regular Price
£556.86
Why Choose the AF116-40-11B-13 [1SFL427102R1311]
The AF116-40-11B-13 is a 4 pole - 690 V IEC or 600 V UL contactor with pre-mounted auxiliary contacts and Main Circuit Bars, controlling motors up to 55 kW / 400 V AC (AC-3) / and switching power circuits up to 160 A (AC-1) or 160 A UL general use. Thanks to the AF technology, the contactor has a wide control voltage range (100-250 V 50/60 Hz and DC), managing large control voltage variations, reducing panel energy consumptions and ensuring distinct operations in unstable networks. Furthermore, surge protection is built-in, offering a compact solution. AF contactors have a block type design, can be easily extended with add-on auxiliary contact blocks and an additional wide range of accessories.
Technical Specification
- Function: 4-pole contactor for motor control up to 55 kW at 400 V AC (AC-3) and power circuits up to 160 A (AC-1).
- Rated Operational Voltage: 690 V IEC / 600 V UL.
- Rated Current: 160 A AC-1 (690 V), 116 A AC-3 (400 V).
- Contact Configuration: 4 main NO contacts, 1 NO auxiliary, 1 NC auxiliary.
- Insulation Voltage: 1000 V IEC / 600 V UL.
- Impulse Withstand Voltage: 8 kV (main circuit).
- Degree of Protection: Auxiliary terminals IP40, coil terminals IP20, main terminals IP00.
- Terminal Type and Size: Main circuit bars; flexible cable up to 70 mm², rigid cable up to 95 mm².
- Mechanical Durability: 5 million operations.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the maximum motor control capacity of the AF116-40-11B-13 contactor?
The AF116-40-11B-13 contactor can control motors up to 55 kW at 400 V AC (AC-3).
What is the rated current for power circuits with this contactor?
The rated current for power circuits is 160 A (AC-1).
What is the control voltage range of the AF116-40-11B-13?
The control voltage range is 100-250 V at 50/60 Hz and DC.
What types of cables can be used with the main circuit bars?
Flexible cables up to 70 mm² and rigid cables up to 95 mm² can be used with the main circuit bars.
Is the AF116-40-11B-13 contactor suitable for unstable networks?
Yes, it is designed to manage large control voltage variations, making it suitable for unstable networks.
What is the degree of protection for the auxiliary terminals?
The degree of protection for the auxiliary terminals is IP40.
What standards and approvals does the AF116-40-11B-13 conform to?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 1SFL427102R1311 |
|---|---|
| Manufacturer | ABB |
| Alternative Product SKU | AF116-40-11B-13 |
| KW Rating | 55kW |
| Inbuilt Aux | 1 N/O 1 N/C |
| Barcode | 7320500503836 |
| Product Lead Time | Please contact us for a delivery time |
Write Your Own Review
ABB AF Contactor RangeABB contactor range can be used to control power circuits up to a level of 690 V AC and 220 V DC. The main benefit of ABB's range of AF products are that only a few coils are needed for different control voltages used in many applications without having to change the coil. |
