ABB XT5N 400 4 pole Normal MCCB Electronic trip unit LS/I Ii=400A
MPN: 1SDA100396R1
Alt. SKU: XT5N 400 Ekip Dip LS/I In=400 4p F F
Special Price
£1,245.34
£1,037.78
Regular Price
£1,915.91
This product replaces this item:
Why Choose the Moulded Case Circuit Breaker [1SDA100396R1]
The TMAX XT5N 400A fixed four-pole circuit breaker features front-access terminals and a solid-state release for precise, reliable protection in AC applications. Designed for integration with the EKIP DIP LS/I R 400 electronic trip unit, it offers advanced monitoring and adjustable trip settings to enhance system safety and performance. This robust device is suitable for industrial and commercial electrical installations requiring dependable overload and short-circuit protection.
Technical Specification
- Function: Moulded Case Circuit Breaker, fixed four-pole.
- Rated Current (In): 400 A.
- Rated Operational Voltage: 690 V AC.
- Rated Insulation Voltage (Ui): 1000 V.
- Rated Impulse Withstand Voltage (Uimp): 8 kV.
- Short-Circuit Breaking Capacity (Ics): Up to 70 kA at 220–240 V AC, decreasing to 20 kA at 690 V AC.
- Release Type: Solid-state release Ekip DIP LS/I (EL type).
- Terminal Connection: Front terminals.
- Electrical Durability: 7,000 cycles at 60 operations/hour.
- Mechanical Durability: 20,000 cycles at 120 operations/hour.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the rated current of the C.BREAKER TMAX XT5N?
The rated current is 400 A.
What is the maximum operational voltage for this circuit breaker?
The maximum rated operational voltage is 690 V AC.
What type of release does this circuit breaker use?
It uses a solid-state release Ekip DIP LS/I (EL type).
What is the short-circuit breaking capacity at 690 V AC?
The short-circuit breaking capacity decreases to 20 kA at 690 V AC.
How durable is the electrical operation of this circuit breaker?
The electrical durability is rated for 7,000 cycles at 60 operations/hour.
What type of terminal connection does this circuit breaker have?
This circuit breaker features front terminals for connection.
What standards and approvals does this product conform to?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 1SDA100396R1 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8056221004732 |
| HS Code | 85362090 |
| Country of Manufacture | Italy |
| Manufacturer | ABB |
| Number of Poles | 3 Pole |
| Amperage | 400A |
| Alternative Product SKU | XT5N 400 Ekip Dip LS/I In=400 4p F F |
