134F8093 Danfoss VLT Refrigeration Drive FC 103 5.5 KW / 7.5 HP, Three phase 380 - 480 VAC, IP20
MPN: 134F8093
Alt. SKU: FC-103P5K5T4E20H1XGXXXXSXXXXAZBXCXXXXDX
Special Price
£1,794.96
£1,495.80
Regular Price
£1,994.40
Why Choose the 134F8093?
The Danfoss 134F8093 (model code FC-103P5K5T4E20H1XGXXXXSXXXXAZBXCXXXXDX) is a Variable speed drive (frequency converter) intended for panel installation where accurate motor control, repeatable commissioning, and reliable like-for-like replacement are required.
Configured with Power: 5.5 KW / 7.5 HP, Current: 11, Supply: 380 - 480 VAC, Phase: Three phase, Enclosure: (E20) IP20 / Chassis, EMC/RFI: RFI filter Class A1 / B to support correct selection and like-for-like replacements.
Key Benefits
- Variable speed drive (frequency converter) for correct application matching
- Configured with Power: 5.5 KW / 7.5 HP, Current: 11, Supply: 380 - 480 VAC, Phase: Three phase, Enclosure: (E20) IP20 / Chassis, EMC/RFI: RFI filter Class A1 / B.
- Suitable for panel installations where reliable commissioning is required.
- SKU and model code shown for procurement and like for like replacements.
Technical Specifications
- Series: 103
- Power Rating: 5.5 KW / 7.5 HP
- Mains Voltage: 380 - 480 VAC
- Phase: Three phase
- Enclosure: (E20) IP20 / Chassis
- RFI Filter: RFI filter Class A1 / B
- Height [mm]: 268,0
- Width w/ no C options [mm]: 130,0
- Depth [mm]: 205,0
- Net weight: 6.49 Kilogram
- EAN: 5710107483754
- A Option: AK-LonWorks MCA 107
- Adaptation A: Standard Cable Entries
- Adaptation B: No adaptation
- B Option: No B Option
- Brake - Safe Stop: No brake chopper
- C Option Software: No software option
- C0 Option MCO: No C0 option
- C1 Option: No C1 option
- Coating PCB: Not coated PCB
- Continuous Current (NO) [A]: 11
- D Option: No D option
- Depth with Option A/B [mm]: 220,0
- Frame Size: A3
- Gross weight: 7.496 Kilogram
- Intermittent Current (NO) [A]: 12.1
- LCP: Graphical Loc. Cont. Panel
- Mains Option: No Mains Option
- Modelcode01: FC-103P5K5T4E20H1XGX
- Modelcode02: XXXSXXXXAZBXCXXXXDX
- Power 110% (NO) [KW]: 5.5
- Power Loss NO [W]: 187
- Product Group: VLT® Refrigeration Drive
- Software Language Pack: Standard Language Pack
- Software Release: Latest release std. SW.
- Typecode Part 1: FC-103P5K5T4E20H1XGX
- Typecode Part 2: XXXSXXXXAZBXCXXXXDX
- Width w/ two C options [mm]: 190,0
Frequently Asked Questions
What supply does Danfoss 134F8093 require?
It is specified for 380 - 480 VAC. Match this to your incoming mains.
What is the rated power for 134F8093?
The listed power rating is 5.5 KW / 7.5 HP. Confirm sizing against your motor and duty cycle.
What enclosure class is it?
It is listed as (E20) IP20 / Chassis and is intended for installation in a suitable cabinet/enclosure as required.
Does it include an EMC/RFI filter?
The configuration is shown as RFI filter Class A1 / B. Choose a filtered variant or external filtering if your site requires it.
Where is 134F8093 typically installed?
In control panels or cabinets. Follow Danfoss installation guidance for clearances, earthing, and protective devices.
What does IP20 mean for 134F8093?
IP20 indicates protection against finger contact and solid objects over 12.5 mm. Install in a suitable enclosure to meet your site requirements.
| Manufacturer Part Number | 134F8093 |
|---|---|
| Barcode | 5710107483754 |
| Height | 268mm |
| Width | 130mm |
| Depth | 205mm |
| Filter | Filter Included |
| Input Phases | Three Phase |
| Degree of protection (IP) | IP20 |
| KW Rating | 5.5kW |
| Output Phases | Three phase |
| VSD Range | Danfoss VLT REFRIGERATION DRIVE FC 103 |
| Manufacturer | Danfoss |
| Alternative Product SKU | FC-103P5K5T4E20H1XGXXXXSXXXXAZBXCXXXXDX |
