131B7537 Danfoss VLT FC-102 HVAC Drive 5.5 KW / 7.5 HP, 380 - 480 VAC, IP20
MPN: 131B7537
Alt. SKU: FC-102P5K5T4E20H1XXXXXXSXXXXAXBXCXXXXDX
Special Price
£953.28
£794.40
Regular Price
£1,588.80
Why Choose the Danfoss 131B7537 VLT HVAC Drive FC-102?
The Danfoss 131B7537 is a compact and energy-efficient AC variable frequency drive (VFD) designed for reliable motor control in HVAC, building services and industrial ventilation applications. As part of the renowned Danfoss VLT HVAC Drive FC-102 series, it is engineered specifically for fans, pumps, compressors and air handling systems where dependable operation and reduced energy consumption are essential.
The VLT HVAC Drive FC-102 range includes intelligent HVAC-focused functions developed to optimise system performance while lowering operational costs. With integrated control features, efficient heat management and built-in protection functions, the drive is ideally suited to modern building automation systems.
With a rated output power of 5.5 kW / 7.5 HP, a three-phase 380–480 V AC supply and a compact IP20 chassis enclosure, the 131B7537 is ideal for HVAC fans, circulation pumps, cooling systems and air handling equipment. Its built-in RFI Class A1/B filter helps support electromagnetic compatibility in suitable installations while simplifying panel integration.
Key Advantages
- Dedicated VLT HVAC Drive for building services applications.
- 5.5 kW / 7.5 HP motor power rating suitable for HVAC fan and pump systems.
- Three-phase 380–480 V AC input compatible with industrial power supplies.
- Built-in RFI Class A1/B filter for improved EMC performance.
- Compact IP20 chassis design for control panel installation.
- Designed to reduce energy consumption and improve HVAC efficiency.
- Reliable Danfoss technology for long-term HVAC motor control applications.
Key Features
- Danfoss VLT HVAC Drive FC-102 series.
- 5.5 kW / 7.5 HP rated output power.
- Three-phase 380–480 V AC input supply.
- IP20 / chassis enclosure format.
- Built-in RFI Class A1/B / C1 filter.
- No brake chopper fitted.
- No local control panel included.
- Frame size A3.
- Not coated PCB.
- Designed for HVAC fan, pump and compressor motor control.
Technical Specifications
- Manufacturer: Danfoss
- Series: VLT HVAC Drive FC-102
- Model: FC-102P5K5T4E20H1XXXXXXSXXXXAXBXCXXXXDX
- Part number: 131B7537
- Product type: AC variable frequency drive
- Rated output power: 5.5 kW / 7.5 HP
- Input voltage: 380–480 V AC
- Input phases: 3-phase
- Output phases: 3-phase
- Supply frequency: 50 / 60 Hz
- Protection rating: IP20 / chassis
- Frame size: A3
- RFI filter: Class A1/B / C1
- Brake chopper: Not included
- Local control panel: Not included
- PCB coating: Not coated
- Application: HVAC fan, pump and building services motor control
Efficient Motor Control for HVAC Systems
Variable frequency drives such as the Danfoss VLT HVAC Drive FC-102 regulate motor speed by adjusting output voltage and frequency. In HVAC systems, this enables fans, pumps and compressors to operate only at the required speed, helping to reduce energy consumption while maintaining precise environmental control.
The 131B7537 is designed for control panel installations in commercial buildings, plant rooms and industrial HVAC systems. Its dedicated HVAC functionality supports efficient building operation while helping improve equipment longevity and overall system performance.
Typical Applications
- HVAC fans and air handling units.
- Building services pumps and circulation systems.
- Ventilation and extraction equipment.
- Heating and cooling plant room systems.
- Industrial fan and pump applications.
- Control panels and building automation installations.
Frequently Asked Questions
What is the Danfoss 131B7537 used for?
The Danfoss 131B7537 is used to control three-phase AC motors in HVAC, ventilation, fan and pump applications.
What motor power is supported by this drive?
This VLT HVAC Drive FC-102 is rated for motors with an output power of approximately 5.5 kW / 7.5 HP.
What supply voltage does the Danfoss 131B7537 require?
The drive operates from a three-phase 380–480 V AC supply.
Does this drive include a brake chopper?
No, the Danfoss 131B7537 configuration does not include a brake chopper.
Does the drive include a local control panel?
No, this configuration is supplied without a local control panel.
Trusted by HVAC and Building Services Engineers
Danfoss VLT HVAC Drive FC-102 inverters are trusted by building services engineers, facilities managers and HVAC specialists for efficient motor control, dependable operation and long-term performance in ventilation and climate control systems.
| Manufacturer Part Number | 131B7537 |
|---|---|
| Barcode | 5702427357365 |
| Height | 268mm |
| Width | 130mm |
| Depth | 205mm |
| Filter | Filter Included |
| Input Phases | Three Phase |
| Degree of protection (IP) | IP20 |
| KW Rating | 5.5kW |
| Output Phases | Three phase |
| VSD Range | Danfoss VLT FC102 |
| Manufacturer | Danfoss |
| Alternative Product SKU | FC-102P5K5T4E20H1XXXXXXSXXXXAXBXCXXXXDX |
Write Your Own Review
The VLT HVAC drive has built-in intelligence to give optimal process control to heating, ventilation and air conditioning (HVAC). It is simple to use and extremely cost-efficient, featuring a number of functions that are ideal for use with pumps, fans and compressors to save energy, meet environmental regulations and reduce costs in modern buildings.
The VLT HVAC drive has a compact, robust design and is ideally suited to locations where space is restricted. A selection of safety features, such as Safe Torque Off and Safe Maximum Speed, protect both applications and their operators.
Enclosures can be purchased separately, up to IP66, and an additional option available upon purchase is a unique coating to provide added protection for the circuit boards. Integrated DC chokes and RFI filters safeguard installations by minimizing harmonic distortion and electromagnetic.
Supply voltages and power range
3 x 200-240 V...1.1-45 kW
3 x 380-480 V...1.1 kW – 1 MW
3 x 525-600 V...1.1-90 kW
3 x 525-690 V...45 kW – 1.4 MW
Low harmonic drive
3 x 380-480 V...132-710 kW
12-pulse drive
3 x 380-480 V...250-200kW
Features and benefits
- There’s no need for external cooling or oversizing as the maximum ambient temperature is 50°C without derating
- PLC capacity is often unnecessary thanks to the Smart Logic Controller
- A low initial investment and easy upgrades are possible thanks to the modular concept with a wide range of options
- The need for external control and conversion equipment is avoided due to integrated pump, fan and compressor functionality
- 5–15% energy is saved as a result of the Automatic Energy Optimization function
- Less gateway solutions are needed thanks to a wide range of HVAC protocols for building management system controller connectivity
Applications
Pumps, fans, compressors.
PC tools
VLT® Motion Control Tool MCT 10
VLT® Motion Control Tool MCT 31
Danfoss ecoSmart
Danfoss HCS (Harmonic Calculation Software)
Danfoss Servo Sizer
VLT® Energy Box
For further information on this product please get in touch with our team or visit the Danfoss website.
