11SMX9010 - ADAPTER PLATE FOR DOL STARTER
MPN: 11SMX9010
Alt. SKU: SMX9010
Why Choose the 11SMX9010?
Designed for straightforward starter assembly integration, the Lovato 11SMX9010 adapter plate is an Accessories item engineered for direct-on-line starter configurations. It enables pairing of an SM1 breaker with BG or BF09A…BF38A contactors, helping you build compact motor starter solutions. Backed by Lovato’s 11SMX product designation, it provides a precise fit within compatible systems.
Conforming to IEC/EN 60947-1 and IEC/EN 60947-5-1, and recognised to UL508 and CSA C22.2 n° 14, this adapter plate supports compliance in UK and global panels. With a lightweight 58 g build and Sustainability certification, it suits SM1P... and SM1R… installations where a tidy interface to BG or BF09A…BF38A contactors is required.
Key Benefits
- Purpose-built adapter plate for direct-on-line starter assemblies.
- Compatible with SM1P... and SM1R… breaker ranges.
- Interfaces with BG or BF09A…BF38A contactors.
- Conforms to IEC/EN 60947-1 and IEC/EN 60947-5-1.
- UL508 and CSA C22.2 n° 14 recognised.
- Lightweight 58 g for easy handling and panel layout.
- Part of Lovato 11SMX accessories range.
Technical Specification
- Product type designation: 11SMX
- Weight: 58 g
What’s Included
- 1 x Lovato 11SMX9010 adapter plate
- Manufacturer datasheet (downloadable)
Applications
- Direct-on-line starter assemblies using SM1 breaker with BG or BF09A…BF38A contactors
- Control panel builds specifying SM1P... or SM1R… compatible accessories
- Maintenance and retrofits of Lovato SM1-based starter systems
- OEM starter assembly standardisation using Lovato accessories
Frequently Asked Questions
What is the Lovato 11SMX9010?
It is an adapter plate for direct-on-line starter assemblies, linking an SM1 breaker with BG or BF09A…BF38A contactors.
Which devices is it compatible with?
It is for SM1P... and SM1R… ranges and BG or BF09A…BF38A contactors.
What standards does it conform to?
It conforms to IEC/EN 60947-1 and IEC/EN 60947-5-1, and is recognised to UL508 and CSA C22.2 n° 14.
How much does the adapter plate weigh?
It weighs 58 g.
What is the product type designation?
The product type designation is 11SMX.
Safety note: Install and service only by qualified personnel. Isolate and de-energise equipment before fitting, and follow the manufacturer’s instructions and applicable standards.
| Manufacturer Part Number | 11SMX9010 |
|---|---|
| Manufacturer | Lovato |
| Packed Quantity | 1 |
| Barcode | 8013975073087 |
| Alternative Product SKU | SMX9010 |
