11RFN910 - T/O RELAY RFN9 6-10A

Why Choose the 11RFN910?

Designed for dependable motor protection, the Lovato 11RFN910 thermal overload relay safeguards three-phase circuits in the 6–10 A range. This non phase failure/non single-phase sensitive, three-pole device features manual resetting and mounts directly on Lovato BG06, BG09, and BG12 mini-contactors. With robust build quality and recognised standards compliance, the 11RFN910 helps prevent overload damage while keeping installations compact and straightforward for panel builders and maintenance teams.

Rated for Ui 690 V and Uimp 8 kV, this relay offers IP20 frontal protection and Pollution Degree 3 performance. It operates reliably from −20 to +55 °C up to 3000 m altitude, with secure connections tightened to 2.3 Nm. Compliance with IEC/EN 60947-1 and 60947-4-1, plus UL508 and CSA C22.2 No. 14, supports use across global control panel standards.

Key Benefits

• Direct mounting on BG06, BG09, and BG12 mini-contactors for quick installation.
• Adjustable 6–10 A range protects a wide span of motor currents.
• Manual reset enables controlled restarts after overload events.
• Three-pole design supports three-phase motor protection.
• High insulation ratings: Ui 690 V and Uimp 8 kV.
• IP20 frontal protection and Pollution Degree 3 for panel environments.
• Operates −20 to +55 °C, up to 3000 m altitude.

Technical Specification

• Number of poles: 3
• Pollution degree: 3
• IP degree (frontal): IP20
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 8 kV
• Terminal tightening torque: 2.3 to 2.3 Nm
• Ith (IEC): 10 A
• Operating temperature: -20 to 55 °C
• Storage temperature: -55 to 70 °C
• Max altitude: 3000 m
• Weight: 123 g

What’s Included

• Lovato 11RFN910 thermal overload relay
• Installation instructions
• Protective packaging

Applications

• Three-phase motor overload protection in control panels
• Motor starters using Lovato BG06, BG09, or BG12 mini-contactors
• OEM equipment requiring 6–10 A thermal protection
• Maintenance replacements in existing Lovato BG installations

Safety note: Ensure settings match the motor current before energising. Installation and adjustment must be performed by qualified personnel with power isolated, following the stated ratings and applicable standards.
