11RFN9075 - T/O RELAY RFN9 0.45-0.75A

Why Choose the 11RFN9075?

Designed for dependable motor protection, the Lovato 11RFN9075 thermal overload relay covers a 0.45 to 0.75 A range. This three-pole, non phase failure / non single‑phase sensitive device features manual resetting for controlled restarts. It mounts directly on BG06, BG09 and BG12 mini-contactors, simplifying compact motor starter assemblies and panel layouts while maintaining consistent performance across low-current three‑phase applications.

Engineered for harsh industrial environments, it offers Ui 690 V and Uimp 8 kV insulation strength with IP20 frontal protection. Rated Ith 10 A, Pollution Degree 3, and suitable for -20 to 55 °C operation up to 3000 m altitude, it supports reliable service in control panels. Compliance with IEC/EN 60947-1 and 60947-4-1, plus UL508 and CSA C22.2 n° 14, underpins assured quality.

Key Benefits

• 0.45–0.75 A setting range for precise low-current motor protection.
• Manual resetting helps prevent unintended automatic motor restarts.
• Direct mounting on BG06, BG09, BG12 for compact assemblies.
• Three-pole design suited to three-phase motor circuits.
• Ui 690 V and Uimp 8 kV ensure robust insulation performance.
• IP20 frontal protection for finger-safe panel integration.
• Operates from -20 to 55 °C, up to 3000 m altitude.
• Conforms to IEC/EN 60947-1/-4-1, UL508 and CSA C22.2 n° 14.

Technical Specification

• Number of poles: 3
• Pollution degree: 3
• IP degree (frontal): IP20
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 8 kV
• Terminal tightening torque: 2.3 to 2.3 Nm
• Ith (IEC): 10 A
• Operating temperature: -20 to 55 °C
• Storage temperature: -55 to 70 °C
• Max altitude: 3000 m
• Weight: 123 g

What’s Included

• 11RFN9075 thermal overload relay unit
• Manufacturer’s installation and safety instructions

Applications

• Motor starters using Lovato BG06, BG09 and BG12 mini-contactors
• Low-current three-phase motor circuits (0.45–0.75 A)
• Industrial control panels requiring IEC/EN 60947-1/-4-1 compliance
• Installations needing manual reset to prevent automatic restarts
• Panels designed with IP20 frontal protection considerations

Safety note: Install and commission only by qualified personnel. Isolate power before work, set within the 0.45–0.75 A range, and follow the manufacturer’s instructions and applicable standards.
