11RFA92V3 - T/O RELAY RFA9 1.4-2.3A

Why Choose the 11RFA92V3?

The Lovato 11RFA92V3 thermal overload relay delivers dependable motor protection for three‑phase applications. This three‑pole, phase‑failure/single‑phase sensitive device features automatic resetting and an adjustable 1.4…2.3 A operational current range. Designed for fast assembly, it mounts directly on BG06, BG09 and BG12 mini‑contactors, helping you streamline panel layouts while safeguarding motors from overload and phase‑loss conditions.

Engineered for durability, it offers Ui 690 V insulation and 8 kV impulse withstand, with IP20 frontal protection and Pollution Degree 3. Rated Ith 10 A, it operates from −20 to 55 °C and up to 3000 m altitude, with storage from −55 to 70 °C. Conformity to IEC/EN 60947‑1 and 60947‑4‑1, UL508 and CSA C22.2 n° 14 underpins compliance. Approximate weight: 116 g.

Key Benefits

• Phase‑failure and single‑phase sensitivity protects against asymmetrical faults.
• Automatic reset restores service swiftly after temporary overloads.
• 1.4…2.3 A setting range suits small three‑phase motors.
• Direct BG06/BG09/BG12 mounting speeds installation and saves space.
• Three‑pole design integrates cleanly with three‑phase contactors.
• Ui 690 V and 8 kV Uimp enhance electrical robustness.
• IP20 frontal protection improves user safety at the terminals.

Technical Specification

• Number of poles: 3
• Pollution degree: 3
• IP degree (frontal): IP20
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 8 kV
• Terminal tightening torque: 2.3 to 2.3 Nm
• Ith (IEC): 10 A
• Operating temperature: -20 to 55 °C
• Storage temperature: -55 to 70 °C
• Max altitude: 3000 m
• Weight: 116 g

What’s Included

• Lovato 11RFA92V3 thermal overload relay
• Quick installation leaflet
• Manufacturer datasheet (PDF)

Applications

• Motor protection in control panels using BG series mini‑contactors
• Pumps, fans and conveyors within the 1.4…2.3 A setting range
• OEM machinery requiring automatic reset after transient overloads
• Retrofit upgrades where phase‑failure sensitivity is essential

Safety note: Installation and adjustment should be performed by qualified personnel. Isolate power before work, set the 1.4…2.3 A adjustment to match the motor, and observe the stated ratings and standards.
