11BGT1210A048 - REVERSING CONTACTOR BGT12.10A 48/50-60
MPN: 11BGT1210A048
Alt. SKU: BGT1210A048
Special Price
£154.74
£128.95
Regular Price
£257.90
Why Choose the 11BGT1210A048?
Lovato’s 11BGT1210A048 is a BGT12 reversing contactor assembly designed for dependable motor direction control in AC systems. It features an AC coil rated 48VAC 50/60Hz, an open-frame format, and a built-in interlock with power wiring only. With 12A AC-3 performance and a 5.7kW rating, it delivers robust switching capability while simplifying panel integration and maintenance.
Backed by IEC/EN 60947-1, IEC/EN 60947-4-1 and UL508 CSA C22.2 n° 14 conformity, this Lovato reversing contactor assembly offers assured compliance. It carries a UL/CSA horsepower rating of 7.5 HP at 480V, and weighs just 380 g for straightforward handling. A practical choice for OEMs and panel builders seeking reliable forward/reverse control with clear specifications and manufacturer-listed sustainability.
Key Benefits
- Built-in interlock with power wiring only enhances reversing safety.
- AC coil 48VAC 50/60Hz suits common control supply standards.
- 12A AC-3 capability provides dependable motor switching performance.
- 5.7kW rating supports robust power handling in AC applications.
- UL/CSA horsepower rating 7.5 HP at 480V broadens compatibility.
- Open-frame design simplifies integration into control panels.
- Conforms to IEC/EN 60947 standards for proven reliability.
Technical Specification
- Product type designation: BGT12
- Weight: 380 g
What’s Included
- Lovato reversing contactor assembly (SKU 11BGT1210A048)
- Built-in interlock (power wiring only), integral to the assembly
- Manufacturer datasheet (downloadable)
- Original manufacturer packaging
Applications
- Forward/reverse control of AC motors in industrial panels
- OEM machinery requiring reliable reversing contactor assemblies
- Maintenance replacements for existing Lovato BGT12 installations
- Training and test benches for motor control setups
Frequently Asked Questions
What coil voltage does the 11BGT1210A048 require?
It uses an AC coil rated at 48VAC 50/60Hz.
What is the AC-3 rating and power rating?
It is rated 12A AC-3 in AC with a 5.7kW power rating.
Does this assembly include control wiring?
No. It has a built-in interlock with power wiring only; control wiring is not included.
What standards does it conform to?
IEC/EN 60947-1, IEC/EN 60947-4-1 and UL508 CSA C22.2 n° 14.
What is the UL/CSA horsepower rating at 480V and the weight?
It is rated 7.5 HP at 480V, and the unit weighs 380 g.
Safety note: Installation and servicing should be performed by qualified personnel. Isolate all power sources before work and follow the manufacturer datasheet and applicable standards.
| Manufacturer Part Number | 11BGT1210A048 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975095683 |
| Alternative Product SKU | BGT1210A048 |
