11BGR0901A024 - REVERSING CONTACTOR BGR09 24/50-60
MPN: 11BGR0901A024
Alt. SKU: BGR0901A024
Special Price
£162.24
£135.20
Regular Price
£270.41
Why Choose the 11BGR0901A024?
Engineered by Lovato, the 11BGR0901A024 is a BGR09 reversing contactor assembly for dependable motor direction control. This open frame unit features an AC coil rated 24VAC 50/60Hz and an external interlock with power and auxiliary wiring. With 9A AC-3 performance and 4 kW capacity, it provides a compact, standards-ready solution for robust reversing duties in control panels.
Certified to IEC/EN 60947-1, IEC/EN 60947-4-1 and UL508 CSA C22.2 n° 14, this assembly offers straightforward integration and reliable switching. It carries a 5 HP rating at 480V (UL/CSA) and weighs 394 g, aiding easy panel layout. The external interlock and preconfigured power and auxiliary wiring help streamline installation and reduce wiring errors in OEM and maintenance projects.
Key Benefits
- External interlock with power and auxiliary wiring simplifies safe reversing control.
- 24VAC 50/60Hz AC coil compatible with common control voltages.
- 9A AC-3, 4kW capability for dependable small motor applications.
- UL/CSA 5 HP at 480V rating supports North American compliance.
- Open frame design aids cooling and straightforward panel integration.
- Conforms to IEC/EN 60947 standards for proven performance.
- Lightweight 394 g unit eases handling and installation.
Technical Specification
- Product type designation: BGR09
- Weight: 394 g
What’s Included
- Lovato BGR09 reversing contactor assembly (open frame)
- External interlock with power and auxiliary wiring
- 24VAC 50/60Hz AC coil installed
- Basic installation and safety information
Applications
- Motor reversing control up to 4 kW (AC-3) in control panels
- OEM machinery requiring compact reversing contactor assemblies
- Industrial automation panels with 24VAC control circuits
- Maintenance replacements for BGR09 reversing assemblies
- Conveyor, pump, and fan direction control within stated ratings
Frequently Asked Questions
What coil voltage does this reversing contactor assembly use?
It has an AC coil rated 24VAC 50/60HZ.
Which standards does this product conform to?
IEC/EN 60947-1, IEC/EN 60947-4-1 and UL508 CSA C22.2 n° 14.
What is the AC-3 motor rating?
It is rated 9A in AC with a 4 kW capacity.
What is the UL/CSA horsepower rating at 480V?
It is rated 5 HP at 480V under UL/CSA.
What construction and interlock features are included?
It is open frame with an external interlock and power and auxiliary wiring.
Safety note: Installation and maintenance must be performed by qualified personnel. Isolate all power, verify the 24VAC 50/60Hz control voltage, and follow IEC/EN 60947 and local regulations before commissioning.
| Manufacturer Part Number | 11BGR0901A024 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975083123 |
| Alternative Product SKU | BGR0901A024 |
