11BGP0901D125 - MINICONTACTOR 3P+1NC 9A AC3 DC REAR PIN
MPN: 11BGP0901D125
Alt. SKU: BGP0901D125
Special Price
£49.24
£41.03
Regular Price
£82.06
Why Choose the 11BGP0901D125?
Designed for dependable motor and control switching, the Lovato BGP09 three-pole contactor (SKU 11BGP0901D125) features a 125 V DC coil and a built-in 1NC auxiliary contact. Delivering 9 A AC-3 (4.0 kW) at 400 V and 20 A AC-1, it suits compact panels. Rear PCB solder pins simplify integration, while screw or 35 mm DIN rail mounting offers flexible installation in OEM equipment and maintenance upgrades.
Built to rigorous standards, this BGP09 contactor offers a 500 V rated insulation (Ui) and 6 kV impulse withstand (Uimp) for robust dielectric performance. With 20,000,000 mechanical operations, -50 to +70 °C operating range, and operation up to 3000 m, it is ready for demanding environments. Terminal tightening torque is 0.8 to 1 Nm. Conforms to IEC/EN 60947-1/-4-1 and UL/CSA equivalents, supporting reliable service in industrial control panels.
Key Benefits
- 9 A AC-3 at 400 V, supporting up to 4.0 kW motors
- 125 V DC coil suited to DC control circuits
- Integrated 1NC auxiliary contact for straightforward signalling or interlocks
- Flexible screw or 35 mm DIN rail mounting options
- High mechanical life of 20,000,000 operations for durability
- Strong dielectric ratings: Ui 500 V and Uimp 6 kV
- Reliable performance from -50 to +70 °C operating temperatures
- Rear PCB solder pins for fast board-level integration
Technical Specification
- Product type designation: BGP09
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 500 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 20 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 240 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BGP09 three-pole contactor, SKU 11BGP0901D125
- Integrated 1NC auxiliary contact
- Rear PCB solder pin interface
- Manufacturer datasheet (downloadable)
Applications
- Starter and reversing circuits for motors up to 4.0 kW at 400 V
- Control panels requiring 125 V DC coil contactors
- HVAC fans, pumps and small compressors
- Conveyors, packaging and material handling equipment
- General-purpose switching in IEC/UL compliant machinery
Frequently Asked Questions
Is the coil AC or DC and what voltage is required?
This contactor has a DC coil rated at 125 V.
What are the main current and power ratings?
AC-3 at 400 V is 9 A / 4.0 kW, and AC-1 Ith is 20 A.
How can I mount this contactor?
It supports screw fixing or 35 mm DIN rail mounting; this version also includes rear PCB solder pins.
What auxiliary contact is included?
A built-in 1NC auxiliary contact is provided.
Which standards does it comply with?
It conforms to IEC/EN 60947-1 and 60947-4-1, UL 60947-1/-4-1, and CSA C22.2 equivalents.
Safety note: Installation must be performed by qualified personnel. Isolate power before work, observe the 0.8–1 Nm terminal torque, and ensure environmental limits (temperature, altitude, pollution degree) are respected.
| Manufacturer Part Number | 11BGP0901D125 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975144961 |
| Alternative Product SKU | BGP0901D125 |
