11BGP0901A400 - 3P MINICONTACTOR 1NC 9A AC3 REAR PIN

Why Choose the 11BGP0901A400?

Engineered for dependable motor and load control, the Lovato BGP09 three‑pole contactor delivers 9A AC3 performance at 400V. The 400V AC 50/60Hz coil ensures stable actuation, while a built‑in 1NC auxiliary contact supports interlocking and signalling. With compact versatility and the robustness expected from Lovato, SKU 11BGP0901A400 suits OEMs and panel builders seeking proven switching reliability in control panels, machinery, and general industrial automation.

Designed for durability, this BGP09 contactor boasts a 20,000,000‑cycle mechanical life and operates from −50 to +70 °C. Rated Ui 500 V and Uimp 6 kV, it withstands demanding environments. Quick to install on screw fixings or 35mm DIN rail, it meets IEC/EN 60947-1/-4-1, UL and CSA standards, supporting consistent performance in global applications where reliability, compliance, and compact footprint matter.

Key Benefits

• 9A AC3 at 400V for dependable small motor control.
• 400V AC 50/60Hz coil provides stable, predictable switching.
• Built‑in 1NC auxiliary contact simplifies interlocking and signalling.
• 20,000,000‑cycle mechanical life reduces maintenance and downtime.
• Operates from −50 to +70 °C for harsh or cold environments.
• Screw or 35mm DIN rail mounting speeds panel installation.
• Rated Ui 500 V and Uimp 6 kV for strong insulation performance.
• Complies with IEC/EN, UL and CSA standards for assured conformity.

Technical Specification

• Product type designation: BGP09
• Number of poles: 3
• Rated insulation voltage Ui (IEC/EN): 500 V
• Rated impulse withstand voltage Uimp: 6 kV
• Ith (IEC): 20 A
• Terminal tightening torque: 0.8 to 1 Nm
• Weight: 198 g
• Mechanical life: 20000000 cycles
• Operating temperature: -50 to +70 °C
• Storage temperature: -60 to +80 °C
• Max altitude: 3000 m
• Pollution degree: 3

What’s Included

• Lovato BGP09 3-pole contactor (SKU 11BGP0901A400)
• Integrated 1NC auxiliary contact
• Installation instructions
• Manufacturer packaging

Applications

• Motor starters up to 9A AC3 at 400V
• Control panels for machinery and OEM equipment
• Pumps, fans and conveyors within 4.0 kW AC3 duty
• Building services and automation control circuits
• General switching of resistive and inductive loads (AC1/AC3)

Safety note: Installation and maintenance must be performed by qualified personnel. Isolate power before work, verify the 400V coil rating matches the control supply, and follow all applicable standards and manufacturer instructions.
