11BGP0901A230 - 3P MINICONTACTOR 1NC 9A AC3 REAR PIN
MPN: 11BGP0901A230
Alt. SKU: BGP0901A230
Special Price
£36.74
£30.62
Regular Price
£61.25
Why Choose the 11BGP0901A230?
Designed for dependable motor control, the Lovato 11BGP0901A230 is a three‑pole contactor with AC3 performance rated 9A at 400V (4.0 kW). It features a 230V AC 50/60Hz coil, a built‑in 1NC auxiliary contact, and rear PCB solder pin connectivity. Compact and robust, this BGP09 series device suits panel builders needing reliable switching in industrial environments.
Engineered to international standards, the contactor offers Ui 500 V and Uimp 6 kV, with Ith 20 A for AC1 duties. It mounts via screw or 35 mm DIN rail, operates from −50 to +70 °C, and endures 20,000,000 mechanical cycles. Compliance with IEC/EN 60947-1/-4-1, UL and CSA supports use across demanding installations.
Key Benefits
- Proven AC3 performance: 9A at 400V for 4.0 kW motors.
- 230V AC 50/60Hz coil suits standard control voltages.
- Built-in 1NC auxiliary contact for straightforward interlocking.
- Screw or 35 mm DIN-rail mounting for fast installation.
- High insulation levels: Ui 500 V and Uimp 6 kV.
- Wide operating temperature −50 to +70 °C for harsh sites.
- Long mechanical life of 20,000,000 cycles minimises downtime.
Technical Specification
- Product type designation: BGP09
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 500 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 20 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 200 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BGP09 three-pole contactor (SKU 11BGP0901A230)
- Built-in 1NC auxiliary contact
- Rear PCB solder pin termination
- Installation and safety information
Applications
- Motor starters for pumps, fans, and conveyors
- General-purpose switching in industrial control panels
- HVAC compressors and air handling units
- Machine tools and automation equipment
- Resistive loads within AC1 duty limits
Frequently Asked Questions
What is the AC3 rating at 400 V?
It is rated 9A at 400V, equivalent to 4.0 kW.
What is the coil specification?
The coil is 230 V AC, 50/60 Hz.
What auxiliary contact is included?
A built-in 1NC auxiliary contact is provided.
How is the contactor mounted?
It mounts via screw fixings or on a 35 mm DIN rail.
Which standards does it conform to?
It conforms to IEC/EN 60947-1 and 60947-4-1, plus UL 60947-1/-4-1 and CSA C22.2 equivalents.
Safety note: Installation must be performed by qualified personnel. Isolate power before work, observe specified terminal torque and applicable standards, and operate within the stated ratings and conditions.
| Manufacturer Part Number | 11BGP0901A230 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975144855 |
| Alternative Product SKU | BGP0901A230 |
