11BGP0901A048 - 3P MINICONTACTOR 1NC 9A 48V50/60 REAR PI
MPN: 11BGP0901A048
Alt. SKU: BGP0901A048
Special Price
£36.74
£30.62
Regular Price
£61.25
Why Choose the 11BGP0901A048?
The Lovato BGP09 three‑pole contactor (SKU 11BGP0901A048) delivers reliable motor switching performance with IEC AC3 current of 9A at 400V and 4.0kW power. Fitted with a 48VAC 50/60Hz coil and a built‑in 1NC auxiliary contact, it suits control circuits and interlocks. Rear PCB solder pin eases panel integration, while screw and 35mm DIN rail mounting options support flexible installation.
Engineered for durability, the BGP09 provides 500V rated insulation, 6kV impulse withstand and a mechanical life of 20000000 cycles. It operates from −50 to +70 °C, up to 3000 m altitude, pollution degree 3. Conforming to IEC/EN and UL/CSA 60947 standards, this contactor supports AC1 20A general‑purpose loads and AC3 motor duties.
Key Benefits
- 9A AC3 at 400V for motor switching
- 48VAC 50/60Hz coil for reliable actuation
- Built-in 1NC auxiliary contact for signalling
- Screw or 35mm DIN rail mounting options
- Rear PCB solder pin for easy integration
- Robust 500V Ui and 6kV Uimp ratings
- Wide −50 to +70 °C operating range
- Long 20000000-cycle mechanical life for endurance
Technical Specification
- Product type designation: BGP09
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 500 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 20 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 200 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BGP09 three-pole contactor (SKU 11BGP0901A048)
- Integrated 1NC auxiliary contact
- Rear PCB solder pin
- Manufacturer installation leaflet and packaging
Applications
- AC motor starters up to 4.0 kW at 400V AC3
- General-purpose AC1 loads up to 20 A
- Control panels with 35mm DIN rail assemblies
- OEM machinery and automation builds
- HVAC, pumps and fans control circuits
Frequently Asked Questions
What is the coil voltage and frequency?
The coil is 48VAC, suitable for 50/60Hz operation.
How many poles and what is its AC3 rating?
It is a three‑pole contactor rated 9A AC3 at 400V (4.0kW).
Does it include an auxiliary contact?
Yes, it has a built‑in 1NC auxiliary contact.
How can this contactor be mounted?
It supports screw fixing or 35mm DIN rail; rear PCB solder pin is provided for integration.
What ambient operating temperatures are supported?
The specified operating range is −50 to +70 °C.
Safety note: Installation and servicing must be performed by qualified personnel. Isolate power before work, observe the stated currents, voltages and torque, and ensure the environment meets temperature, altitude and pollution degree limits.
| Manufacturer Part Number | 11BGP0901A048 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975144787 |
| Alternative Product SKU | BGP0901A048 |
| Coil Voltage | 48V |
