11BGF09T4A400 - 4P MINICONTACTOR BGF09.T4A 400V50/60FAST
MPN: 11BGF09T4A400
Alt. SKU: BGF09T4A400
Special Price
£43.37
£36.14
Regular Price
£72.28
Why Choose the 11BGF09T4A400?
Designed for reliable motor and load switching, the Lovato BGF09 four‑pole contactor (SKU 11BGF09T4A400) features a 400 V AC 50/60 Hz coil and convenient Faston terminals. With AC‑3 performance of 9 A/4.0 kW at 400 V and an Ith of 20 A, it suits demanding control panels. Compact and quick to install on 35 mm DIN rail or with screws, it streamlines assembly.
Built for endurance and safety, this contactor offers 690 V rated insulation (Ui) and 6 kV impulse withstand (Uimp), plus a mechanical life of 20,000,000 cycles. It operates from −50 to +70 °C and up to 3000 m, Pollution Degree 3. UL/CSA horsepower rating is 5 HP at 480 V. Compliant with IEC/EN 60947-1/-4-1, UL and CSA standards, with 0.8–1 Nm terminal tightening torque.
Key Benefits
- Reliable four-pole switching with 9 A/4.0 kW AC-3 at 400 V.
- 400 V AC 50/60 Hz coil for wide control circuit compatibility.
- Faston terminals speed panel wiring and reduce installation time.
- DIN rail 35 mm or screw mount for flexible assembly.
- High endurance: 20,000,000 mechanical cycles for long service life.
- Robust insulation: Ui 690 V and 6 kV impulse withstand.
- Operates −50 to +70 °C; suitable up to 3000 m altitude.
Technical Specification
- Product type designation: BGF09
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 20 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 176 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato four-pole contactor, SKU 11BGF09T4A400
- Installation/quick-start leaflet
- Access to manufacturer datasheet (PDF)
Applications
- Motor starters and reversing circuits within rated AC-3 limits
- Control of pumps, fans and compressors in industrial panels
- Switching of heating elements and resistive loads (AC-1 up to 20 A)
- Distribution and lighting control circuits using four-pole configurations
- OEM machinery and process equipment requiring DIN rail contactors
Frequently Asked Questions
What coil voltage and frequency does this contactor use?
It has a 400 V AC 50/60 Hz coil.
What is the AC-3 current and power rating at 400 V?
It is rated at 9 A / 4.0 kW at 400 V AC-3.
How is it mounted and what terminals does it have?
It mounts on 35 mm DIN rail or by screws and uses Faston terminals.
What are the operating temperature range and mechanical life?
Operating temperature is −50 to +70 °C; mechanical life is 20,000,000 cycles.
Which standards does the 11BGF09T4A400 comply with?
It meets IEC/EN 60947-1/-4-1, UL 60947-1/-4-1 and CSA C22.2 60947-1/-4-1.
Safety note: Installation must be performed by qualified personnel. Isolate power before work, tighten terminals to 0.8–1 Nm, and operate within the specified ratings, temperature, altitude and standards.
| Manufacturer Part Number | 11BGF09T4A400 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975121566 |
| Alternative Product SKU | BGF09T4A400 |
