11BGF09T4A110 - 4P MINICONTACTOR BGF09.T4A 110V 50/60FAS
MPN: 11BGF09T4A110
Alt. SKU: BGF09T4A110
Special Price
£43.37
£36.14
Regular Price
£72.28
Why Choose the 11BGF09T4A110?
The Lovato BGF09 four‑pole contactor with 110VAC AC coil (50/60Hz) features Faston terminals and flexible mounting via screw fixings or 35mm DIN rail. Built for dependable switching in AC‑1 and AC‑3 duties, it delivers 20 A Ith and 9 A/4.0 kW at 400 V. SKU 11BGF09T4A110 also provides robust insulation (Ui 690 V) and 6 kV impulse withstand.
Engineered for harsh environments, this contactor operates from −50 to +70 °C and up to 3000 m altitude, with Pollution Degree 3. A mechanical life of 20,000,000 cycles reduces maintenance downtime. Conformity with IEC/EN 60947 and UL/CSA standards supports panel compliance, while quick Faston wiring and compact 180 g construction streamline installation in OEM and upgrade projects.
Key Benefits
- Four-pole design for flexible power and control circuit switching.
- 110 VAC 50/60Hz coil suits common control voltages.
- AC-3 rating 9A/4.0kW at 400V for motor loads.
- High mechanical life of 20,000,000 cycles ensures durability.
- Wide operating temperature range from -50 to +70 °C.
- Screw or 35mm DIN rail mounting for quick installation.
- 690 V insulation and 6 kV impulse withstand enhance safety.
- Faston terminals enable rapid, reliable wiring.
Technical Specification
- Product type designation: BGF09
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 20 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 180 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato four-pole contactor, model 11BGF09T4A110
- Quick start and installation leaflet
- Manufacturer conformity and certification details
- Original manufacturer packaging
Applications
- Motor control up to 4.0 kW at 400 V (AC-3 duty)
- Resistive load switching up to 20 A (AC-1 duty)
- Control panels requiring 110VAC coil with screw or DIN rail mounting
- Industrial equipment designed to IEC/EN 60947 standards
- Systems needing four-pole switching for power and control circuits
Frequently Asked Questions
What is the coil voltage and frequency?
The coil is AC 50/60Hz with a rated voltage of 110 V.
Can this contactor be mounted on a DIN rail?
Yes, it supports screw mounting or 35 mm DIN rail installation.
What are the AC-3 ratings at 400 V?
It is rated 9 A / 4.0 kW for AC-3 duty at 400 V.
Which standards does it conform to?
It conforms to IEC/EN 60947-1/-4-1 and UL/CSA 60947 standards.
What environmental limits does it support?
It operates from -50 to +70 °C and up to 3000 m altitude.
Safety note: Install and service only when de-energised by qualified personnel. Follow IEC/EN 60947 and manufacturer instructions; tighten terminals to 0.8–1 Nm and observe local regulations.
| Manufacturer Part Number | 11BGF09T4A110 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975121474 |
| Alternative Product SKU | BGF09T4A110 |
