11BGF0910D110 - MINICONTACTOR 3P+1NO 9A DC/COIL FASTON
MPN: 11BGF0910D110
Alt. SKU: BGF0910D110
Special Price
£50.76
£42.30
Regular Price
£84.59
Why Choose the 11BGF0910D110?
The Lovato BGF09 three-pole contactor (SKU 11BGF0910D110) delivers reliable switching for industrial control panels. With a 110 V DC coil and AC-3 rating of 9 A at 400 V (4.0 kW), it integrates a 1NO auxiliary contact for straightforward signalling. Screw or 35 mm DIN rail mounting streamlines installation, while Faston terminals support quick connections in space-constrained enclosures.
Engineered for demanding environments, the BGF09 is rated Ui 690 V with 6 kV impulse withstand, operates from -50 to +70 °C, and endures up to 20,000,000 mechanical cycles. Rated for pollution degree 3 and installation up to 3000 m, it complies with IEC/EN, UL and CSA standards for motor and general-purpose switching in industrial automation.
Key Benefits
- AC-3 switching up to 9 A at 400 V for small motors.
- 110 V DC coil delivers stable operation and control compatibility.
- Integrated 1NO auxiliary contact simplifies status signalling.
- Screw or 35 mm DIN rail mounting for flexible installation.
- Wide -50 to +70 °C operating range suits harsh environments.
- High 20,000,000-cycle mechanical life minimises downtime.
- Rated Ui 690 V and Uimp 6 kV for robust insulation.
- Faston terminals enable quick, tidy wiring.
Technical Specification
- Product type designation: BGF09
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 20 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 210 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BGF09 three-pole contactor, 110 V DC coil (SKU 11BGF0910D110)
- Integrated 1NO auxiliary contact
- Screw/DIN rail mounting capability
- Manufacturer datasheet (online)
Applications
- AC-3 motor starters up to 4.0 kW at 400 V
- General-purpose AC-1 switching up to 20 A
- Industrial control panels and OEM machinery
- Conveyors, pumps, fans and small compressors
Frequently Asked Questions
What coil voltage does this contactor use?
It uses a 110 V DC coil.
What is the AC-3 rating at 400 V?
It is rated 9 A (4.0 kW) at 400 V in AC-3.
How can the contactor be mounted?
It supports screw mounting or 35 mm DIN rail mounting.
Does it include auxiliary contacts?
Yes, it has a built-in 1NO auxiliary contact.
What operating temperature range is supported?
It operates from -50 to +70 °C.
Safety note: Installation and maintenance must be performed by qualified personnel. Isolate power before work and observe Ui, Uimp, temperature, altitude and pollution degree limits in accordance with IEC/EN 60947 and local regulations.
| Manufacturer Part Number | 11BGF0910D110 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975121382 |
| Alternative Product SKU | BGF0910D110 |
