11BGF0910A110 - 3P MINICONTACTOR BGF09.10A 110V50/60FAST
MPN: 11BGF0910A110
Alt. SKU: BGF0910A110
Special Price
£42.17
£35.14
Regular Price
£70.27
Why Choose the 11BGF0910A110?
The Lovato BGF09 three‑pole contactor (SKU 11BGF0910A110) delivers reliable motor switching with an AC3 rating of 9A at 400V (4.0 kW). Equipped with a 110VAC AC coil (50/60Hz) and an integrated 1NO auxiliary contact, it features Faston terminals for quick, secure connections. Compact and versatile, it suits DIN rail (35mm) or screw mounting, supporting efficient panel builds and maintenance in industrial environments.
Built for demanding conditions, this contactor offers Ui 690V, Uimp 6kV and Ith (AC1) 20A, with a mechanical life rated to 20,000,000 cycles. It operates from −50 to +70 °C up to 3000 m altitude, and meets IEC/EN 60947-1/-4-1 plus UL/CSA equivalents. The BGF09 designation assures consistent performance and straightforward integration into control panels, with 0.8–1 Nm terminal torque simplifying accurate, repeatable installation.
Key Benefits
- 9A AC3 at 400V, suitable for 4.0 kW motor loads.
- Wide -50 to +70 °C operating temperature for harsh environments.
- Faston terminals enable rapid, secure wiring and maintenance.
- 110VAC 50/60Hz coil simplifies control circuit compatibility.
- Integrated 1NO auxiliary contact for status or interlocks.
- Screw or 35mm DIN rail mounting for flexible installation.
- High mechanical life rated 20,000,000 cycles reduces downtime.
- Conforms to IEC/EN and UL/CSA standards for assured compliance.
Technical Specification
- Product type designation: BGF09
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 20 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 180 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BGF09 three-pole contactor, SKU 11BGF0910A110
- Integrated 1NO auxiliary contact
- Faston connection terminals
- DIN rail (35mm) and screw mounting capability
Applications
- AC3 motor switching up to 9A / 4.0 kW at 400 V
- Pumps, fans, compressors and small conveyors
- OEM control panels and MCCs
- General industrial automation and machinery
- Switching resistive AC1 loads up to 20 A
Frequently Asked Questions
What coil voltage does this contactor use?
It has a 110VAC coil suitable for 50/60Hz operation.
Is an auxiliary contact included?
Yes, it includes a built‑in 1NO auxiliary contact.
How can this contactor be mounted?
It supports screw mounting or 35mm DIN rail installation.
What is the AC3 switching capability?
It is rated 9A at 400V, suitable for 4.0 kW motor loads.
Which standards does it comply with?
It conforms to IEC/EN 60947-1/-4-1 and equivalent UL/CSA standards.
Safety note: Installation must be carried out by qualified personnel. Isolate power before work, tighten terminals to 0.8–1 Nm, and follow applicable IEC/EN, UL and CSA safety standards.
| Manufacturer Part Number | 11BGF0910A110 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975121238 |
| Alternative Product SKU | BGF0910A110 |
| Coil Voltage | 230V |
