11BGF0031A400 - CONTROL RELAY BGF00.31A 400V 50/60FASTON
MPN: 11BGF0031A400
Alt. SKU: BGF0031A400
Special Price
£37.14
£30.95
Regular Price
£61.91
Why Choose the 11BGF0031A400?
Designed for dependable switching in control panels, the Lovato control relay SKU 11BGF0031A400 delivers precise operation with an AC coil rated 400 VAC at 50/60 Hz. Its 4‑pole configuration with 3NO+1NC auxiliary contacts supports versatile control logic, while Faston terminals speed installation. Compact and robust, it integrates cleanly into new builds or retrofits where reliable control circuit performance and clear contact states are essential.
Engineered to withstand demanding environments, this BGF00 series relay offers a 20,000,000‑cycle mechanical life and operates from −50 to +70 °C up to 3000 m altitude. Rated Ui 690 V and Uimp 6 kV with Ith 10 A, it mounts via screw fixing or on 35 mm DIN rail. Conformity to IEC/EN 60947-1 and 60947-5-1 (plus UL and CSA equivalents) supports compliance in UK industrial installations.
Key Benefits
- 400 VAC 50/60 Hz AC coil ensures stable, reliable actuation.
- 3NO+1NC contacts deliver flexible control and interlocking options.
- High insulation ratings: Ui 690 V and Uimp 6 kV.
- Long service life with 20,000,000 mechanical operating cycles.
- Wide −50 to +70 °C operating temperature for harsh environments.
- Screw or 35 mm DIN rail mounting simplifies panel assembly.
- Faston terminals enable quick, tool‑efficient wiring.
- 4‑pole design supports compact, multi-circuit control schemes.
Technical Specification
- Product type designation: BGF00
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 10 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 180 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BGF00 control relay, SKU 11BGF0031A400
- Manufacturer datasheet (PDF)
- Original packaging
Applications
- Industrial control panels and machine automation circuits
- Interlocking, signalling and auxiliary switching in control systems
- HVAC plant and building services control cabinets
- Power distribution auxiliaries and load shedding schemes
- OEM panel building and retrofit projects
Frequently Asked Questions
What is the coil voltage and frequency?
It has a 400 V AC coil rated for 50/60 Hz operation.
How many contacts does it have?
It is a 4‑pole device with 3NO + 1NC auxiliary contacts.
How is it mounted?
It mounts on a 35 mm DIN rail or via screw fixing.
What environmental limits does it support?
It operates from −50 to +70 °C and up to 3000 m altitude.
Which standards does it comply with?
It conforms to IEC/EN 60947-1 and 60947-5-1, plus UL and CSA equivalents.
Safety note: Installation and commissioning must be performed by qualified personnel. Observe all specified electrical ratings and environmental limits, and follow IEC/EN 60947 and applicable site regulations for safe operation.
| Manufacturer Part Number | 11BGF0031A400 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975120590 |
| Alternative Product SKU | BGF0031A400 |
| Coil Voltage | 400V |
