11BGF0031A110 - CONTROL RELAY BGF00.31A 110V50/60 FASTON

Why Choose the 11BGF0031A110?

The Lovato BGF00 control relay, SKU 11BGF0031A110, delivers reliable switching for AC and DC control circuits. With a 110VAC 50/60Hz coil and four poles configured 3NO+1NC, it suits interlocking and signalling duties. Faston terminals speed panel wiring, while DIN rail 35mm or screw mounting ensures flexible installation. Rated insulation 690 V and 6 kV impulse withstand add robustness for industrial environments.

Built for endurance, the relay offers Ith 10 A and a mechanical life of 20,000,000 cycles. It operates from -50 to +70 °C up to 3000 m altitude, Pollution Degree 3, with terminal tightening torque 0.8–1 Nm. Compliance with IEC/EN 60947-1 and 60947-5-1, plus UL and CSA equivalents, supports consistent performance and panel standardisation.

Key Benefits

• 110VAC 50/60Hz coil for dependable control circuit operation.
• 4-pole, 3NO+1NC contacts offer versatile auxiliary switching.
• Faston terminals enable quick connection during panel assembly.
• DIN rail 35mm or screw mounting simplifies installation.
• High insulation 690 V and 6 kV impulse withstand.
• Wide -50 to +70 °C operating temperature range.
• Mechanical life of 20,000,000 cycles reduces downtime.
• Ith 10 A suitable for typical auxiliary circuits.

Technical Specification

• Product type designation: BGF00
• Number of poles: 4
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 6 kV
• Ith (IEC): 10 A
• Terminal tightening torque: 0.8 to 1 Nm
• Weight: 180 g
• Mechanical life: 20000000 cycles
• Operating temperature: -50 to +70 °C
• Storage temperature: -60 to +80 °C
• Max altitude: 3000 m
• Pollution degree: 3

What’s Included

• Lovato BGF00 control relay (SKU 11BGF0031A110)
• Installation instructions
• Original manufacturer packaging

Applications

• AC and DC control circuits in industrial panels
• Interlocking and auxiliary switching tasks
• Signalling and indication circuits
• General-purpose control relay functions

Safety note: Install and service only when power is isolated. Observe rated voltages, environmental limits, and terminal tightening torque 0.8–1 Nm, and follow applicable IEC/EN 60947 practices.
