11BGF0022D024 - CONTROL RELAY BGF00.22D 24VDC FASTON

Why Choose the 11BGF0022D024?

Lovato’s 11BGF0022D024 is a robust control relay for AC and DC control circuits, built for dependable switching in industrial panels. It features a 24 V DC coil driving four poles with 2NO+2NC auxiliary contacts. Faston terminals support quick connection, while screw or 35 mm DIN rail mounting makes integration straightforward for OEMs and maintenance engineers.

Engineered for longevity and resilience, it offers a mechanical life of 20,000,000 cycles, Ui 690 V and Uimp 6 kV, with Ith rated at 10 A. Operates from -50 to +70 °C up to 3000 m altitude, Pollution degree 3. Conforms to IEC/EN 60947-1 and 60947-5-1, plus UL and CSA equivalents, ensuring reliable compliance in demanding environments.

Key Benefits

• 24 V DC coil for reliable actuation in control circuits.
• 4-pole design with 2NO+2NC auxiliary contacts.
• Faston terminals enable quick, tool-free wiring changes.
• Screw or 35 mm DIN rail mounting for easy installation.
• High insulation ratings: Ui 690 V, Uimp 6 kV.
• Long mechanical life of 20,000,000 switching cycles.
• Operates -50 to +70 °C, suitable for harsh environments.

Technical Specification

• Product type designation: BGF00
• Number of poles: 4
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 6 kV
• Ith (IEC): 10 A
• Terminal tightening torque: 0.8 to 1 Nm
• Weight: 212 g
• Mechanical life: 20000000 cycles
• Operating temperature: -50 to +70 °C
• Storage temperature: -60 to +80 °C
• Max altitude: 3000 m
• Pollution degree: 3

What’s Included

• Lovato control relay 11BGF0022D024 (BGF00)
• Downloadable datasheet and technical documentation
• Original manufacturer packaging

Applications

• Industrial control panels and automation circuits
• Auxiliary switching and signalling in machinery
• Interlocking and logic functions in OEM equipment
• HVAC and building services control
• Distribution boards requiring 24 V DC coil relays

Safety note: Install and service only by competent personnel with the circuit isolated. Observe the specified torque, temperature range, altitude and pollution degree, and comply with IEC/EN 60947 and local regulations.
