11BG1201D060 - 3P MINICONTACTOR BG12.01D 60V
MPN: 11BG1201D060
Alt. SKU: BG1201D060
Special Price
£45.37
£37.81
Regular Price
£75.61
Why Choose the 11BG1201D060?
Engineered for reliable motor control, the Lovato BG12 three-pole contactor (SKU 11BG1201D060) combines a 60VDC DC coil with AC-3 performance of 12 A / 5.7 kW at 400 V. It includes an integrated 1NC auxiliary with mirror contact function and an AC-1 rating of 20 A. Versatile screw or 35 mm DIN-rail mounting simplifies panel integration and supports quick installation in space-limited control enclosures.
Designed for demanding environments, it offers Ui 690 V and 6 kV impulse withstand, a wide -50…+70 °C operating range, and a mechanical life of 20,000,000 cycles. Rated 7.5 HP at 480 V (UL/CSA), the BG12 meets IEC/EN 60947-1 and 60947-4-1 plus UL and CSA standards, delivering dependable performance across industrial automation, HVAC, and general-purpose panel-building applications.
Key Benefits
- AC-3 12 A / 5.7 kW at 400 V for motor duties.
- 60VDC coil ensures precise, stable control in DC systems.
- Integrated 1NC auxiliary with mirror contact for safety interlocking.
- Long mechanical life rated to 20,000,000 cycles.
- Wide operating temperature range from -50 to +70 °C.
- High insulation: Ui 690 V and Uimp 6 kV.
- Flexible screw or 35 mm DIN-rail mounting.
Technical Specification
- Product type designation: BG12
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 20 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 228 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BG12 three-pole contactor (SKU 11BG1201D060)
- Integrated 1NC auxiliary mirror contact
- Installation leaflet
Applications
- Motor control up to 12 A AC-3 / 5.7 kW at 400 V
- General AC-1 switching up to 20 A
- Industrial automation panels and control cabinets
- HVAC fans, pumps and conveyors within rating
Frequently Asked Questions
What coil voltage does this contactor use?
It has a DC coil rated at 60 VDC.
How is the contactor mounted?
It supports screw mounting or 35 mm DIN-rail mounting.
What auxiliary contacts are included?
It includes one built-in 1NC auxiliary with mirror contact function.
What is the operating temperature range?
The operating temperature range is -50 to +70 °C.
Which standards does it comply with?
It conforms to IEC/EN 60947-1 and 60947-4-1, plus UL and CSA equivalents.
Safety note: Installation and maintenance must be performed by qualified personnel. Always isolate power supplies before wiring or servicing and ensure the device is applied within its stated ratings and standards.
| Manufacturer Part Number | 11BG1201D060 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975082867 |
| Alternative Product SKU | BG1201D060 |
| Coil Voltage | 60V |
