11BG09T4D060 - MINICONTACTOR 4P NO 20A AC1 DC COIL

Why Choose the 11BG09T4D060?

Designed for dependable switching, the Lovato BG09 four‑pole contactor with a 60 V DC coil (SKU 11BG09T4D060) delivers solid performance in AC1 and AC3 duties. It is rated 20 A (AC1) and 9 A / 4.0 kW at 400 V (AC3), combining compact size with easy installation. At just 220 g, it mounts quickly on 35 mm DIN rail or by screws to suit your panel layout.

Built to rigorous standards, this contactor conforms to IEC/EN 60947-1 and 60947-4-1, plus UL and CSA standards. It offers 690 V Ui and 6 kV impulse withstand, with mechanical life of 20,000,000 cycles. Rated for -50 to +70 °C operation, up to 3000 m altitude and pollution degree 3, terminals tighten to 0.8–1 Nm for secure connections.

Key Benefits

• Four-pole design for versatile multi-circuit switching.
• 60 V DC coil suited to DC control systems.
• AC3 rating 9 A / 4.0 kW at 400 V.
• AC1 rating 20 A for resistive loads.
• Quick screw or 35 mm DIN rail mounting.
• High endurance: 20,000,000 mechanical cycles.
• Wide operating temperature range -50 to +70 °C.

Technical Specification

• Product type designation: BG09
• Number of poles: 4
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 6 kV
• Ith (IEC): 20 A
• Terminal tightening torque: 0.8 to 1 Nm
• Weight: 220 g
• Mechanical life: 20000000 cycles
• Operating temperature: -50 to +70 °C
• Storage temperature: -60 to +80 °C
• Max altitude: 3000 m
• Pollution degree: 3

What’s Included

• Lovato BG09 four-pole contactor, 60 V DC coil (SKU 11BG09T4D060)
• Manufacturer data sheet (downloadable)
• Original manufacturer packaging

Applications

• Motor switching up to 9 A / 4.0 kW at 400 V (AC3)
• Resistive load control up to 20 A (AC1)
• Control panels requiring a 60 V DC coil
• DIN rail or screw-mounted industrial assemblies

Safety note: Install and service only by qualified personnel. Isolate power before work, follow IEC/EN 60947 guidance, and tighten terminals to 0.8–1 Nm. Do not exceed stated ratings or environmental limits.
