11BG09T4A02460 - 4P MINICONTACTOR BG09.T4A 24V 60HZ
MPN: 11BG09T4A02460
Alt. SKU: BG09T4A02460
Special Price
£35.62
£29.68
Regular Price
£59.36
Why Choose the 11BG09T4A02460?
The Lovato BG09 four-pole contactor (SKU 11BG09T4A02460) delivers reliable switching for industrial control. It features a 24VAC 60Hz coil, 20 A Ith (AC1) and 9A/4.0kW AC3 at 400V, with 5 HP at 480V to UL/CSA. Rated Ui 690 V and Uimp 6 kV, it mounts via screws or 35mm DIN rail for fast installation.
Built for demanding environments, this BG09 contactor offers 20,000,000 mechanical cycles and operates from -50 to +70 °C, with storage down to -60 °C. Rated to Pollution Degree 3 and 3000 m altitude, it meets IEC/EN and UL/CSA standards. Compact at 200 g, with 0.8 to 1 Nm terminal torque, it suits panels requiring assured performance and compliance.
Key Benefits
- Four-pole BG09 contactor for flexible multi-circuit control.
- 24VAC 60Hz coil simplifies low-voltage control integration.
- AC1 Ith 20 A; AC3 9A/4.0kW at 400V performance.
- Ui 690 V and 6 kV Uimp enhance dielectric reliability.
- Dual mounting: screw fixings or 35mm DIN rail.
- Operates from -50 to +70 °C for harsh environments.
- Twenty million mechanical operations reduce downtime and servicing.
Technical Specification
- Product type designation: BG09
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 20 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 200 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BG09 four-pole contactor, 24VAC 60Hz coil
- Installation and safety information leaflet
Applications
- Motor starters up to 4.0 kW at 400V (AC3)
- Resistive load switching up to 20 A (AC1)
- Multi-circuit control requiring four poles
- OEM machinery and automation panels
- Pumps, fans and compressors up to 5 HP at 480V (UL/CSA)
Frequently Asked Questions
What coil voltage and frequency does this contactor use?
It has a 24VAC, 60Hz AC coil.
What are the AC3 and AC1 ratings?
It is rated 9A/4.0kW at 400V (AC3) and 20 A Ith (AC1).
How is the BG09 contactor mounted?
It mounts with screws or on a 35 mm DIN rail.
Which standards does it conform to?
It conforms to IEC/EN 60947-1/-4-1 and UL/CSA equivalents.
What is the operating temperature range?
The operating range is -50 to +70 °C, with storage -60 to +80 °C.
Safety note: Install and commission by qualified personnel only, observing the specified terminal torque and applicable standards. Disconnect power before work and ensure protection appropriate to the application.
| Manufacturer Part Number | 11BG09T4A02460 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975082089 |
| Alternative Product SKU | BG09T4A02460 |
| Coil Voltage | 24V |
