11BG0610D125 - MINICONTACTOR BG06.10D 125VDC
MPN: 11BG0610D125
Alt. SKU: BG0610D125
Special Price
£41.09
£34.24
Regular Price
£68.47
Why Choose the 11BG0610D125?
Built for dependable motor control, the Lovato BG06 three‑pole contactor (SKU 11BG0610D125) combines a 125V DC coil with robust AC switching performance. Rated 6A AC3 at 400V (2.2 kW) and 16A AC1, it includes a built‑in 1NO auxiliary contact and supports screw or 35mm DIN‑rail mounting for fast panel integration.
Engineered to IEC/EN 60947 and UL/CSA standards, this BG06 device delivers durability and safety in demanding environments. With Ui 690V, Uimp 6kV, and mechanical life of 20,000,000 cycles, it performs from -50 to +70°C up to 3000m altitude (pollution degree 3). Terminal torque is 0.8–1 Nm; UL/CSA 480V rating is 3 HP.
Key Benefits
- Reliable AC3 motor switching, 6A at 400V, 2.2 kW rated.
- Wide operating range, -50 to +70°C, up to 3000 m altitude.
- Long mechanical life, 20,000,000 cycles for reduced maintenance.
- 125V DC coil ensures stable control in DC-powered panels.
- Built-in 1NO auxiliary contact for straightforward signalling.
- Screw or 35 mm DIN-rail mounting for quick installation.
- High insulation levels: Ui 690 V, Uimp 6 kV.
Technical Specification
- Product type designation: BG06
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 16 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 220 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BG06 three-pole contactor, DC coil 125V (SKU 11BG0610D125)
- Integrated 1NO auxiliary contact
- Manufacturer datasheet (downloadable)
- Compliance and certification information
Applications
- AC motor starters up to 6A AC3 at 400V (2.2 kW)
- Control panels requiring 125V DC coil contactors
- OEM machinery and automation circuits
- General-purpose switching in industrial distribution boards
- Pumping, fans and conveyors with IEC/UL compliance
Frequently Asked Questions
What is the coil voltage and type?
It uses a DC coil rated at 125 V for control.
Can this contactor be DIN-rail mounted?
Yes, it supports screw mounting or 35mm DIN‑rail installation.
Does it include auxiliary contacts?
Yes, it has a built‑in 1NO auxiliary contact.
What are the main current and power ratings?
It is rated 6A AC3 at 400V (2.2 kW) and 16A AC1.
Which standards does it comply with?
It conforms to IEC/EN 60947-1/-4-1, UL 60947-1/-4-1, and CSA equivalents.
Safety note: Install and maintain only by qualified personnel. Isolate power before work, observe specified torque and temperature limits, and follow applicable IEC/UL/CSA standards.
| Manufacturer Part Number | 11BG0610D125 |
|---|---|
| Manufacturer | Lovato |
| Barcode | 8013975082690 |
| Alternative Product SKU | BG0610D125 |
| Coil Voltage | 125VDC |
