11BG0610A048 - 3P MINICONTACTOR BG06.10A 48V 50/60Hz
MPN: 11BG0610A048
Alt. SKU: BG0610A048
Special Price
£30.10
£25.08
Regular Price
£50.16
Why Choose the 11BG0610A048?
Engineered for reliable motor switching, the Lovato BG06 three-pole contactor (SKU 11BG0610A048) features a 48 VAC 50/60 Hz coil and AC-3 6 A (2.2 kW at 400 V) performance. A built-in 1NO auxiliary contact simplifies control circuits, while compact screw or 35 mm DIN-rail mounting speeds installation. With 16 A Ith (AC-1) capability, it’s a versatile contactor for compact panels and OEM machinery.
Built to endure demanding environments, the BG06 offers 690 V rated insulation (Ui) and 6 kV impulse withstand (Uimp), a mechanical life of 20,000,000 cycles, and operation from -50 to +70 °C. Terminals tighten to 0.8 to 1 Nm and suit screw or DIN rail mounting. At just 177 g, it complies with IEC/EN 60947-1/-4-1, UL 60947-1/-4-1 and CSA C22.2 60947-1/-4-1.
Key Benefits
- Reliable AC-3 6 A (2.2 kW at 400 V) motor switching.
- 48 VAC 50/60 Hz coil for global control panel compatibility.
- Built-in 1NO auxiliary contact simplifies signalling and interlocks.
- Compact screw or 35 mm DIN rail mounting flexibility.
- High endurance: 20,000,000 mechanical operations for long service life.
- Wide operating temperature range from -50 to +70 °C.
- Robust insulation: Ui 690 V and Uimp 6 kV for resilience.
Technical Specification
- Product type designation: BG06
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 16 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 177 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BG06 three-pole contactor, 48 VAC coil (SKU 11BG0610A048)
- Integrated 1NO auxiliary contact
- Manufacturer datasheet and documentation
- Protective packaging for transit
Applications
- Switching three-phase motors up to 2.2 kW at 400 V AC-3
- OEM machine panels requiring compact 48 VAC control circuits
- HVAC fan, pump and small conveyor starters
- General-purpose motor control and reversing schemes (with appropriate interlocks)
- Industrial control cabinets using screw or DIN rail mounting
Frequently Asked Questions
What coil voltage does this contactor use?
It has a 48 VAC coil rated for 50/60 Hz operation.
What is the AC-3 rating at 400 V?
It is rated at 6 A, equivalent to 2.2 kW at 400 V AC-3.
Does it include an auxiliary contact?
Yes, it comes with a built-in 1NO auxiliary contact.
How can this contactor be mounted?
It supports screw mounting or 35 mm DIN rail mounting.
Which standards does it comply with?
It complies with IEC/EN 60947-1/-4-1, UL 60947-1/-4-1 and CSA C22.2.
Safety note: Install and commission only by qualified personnel. Isolate all power sources before wiring or maintenance, observe specified torque and ratings, and follow applicable standards and local regulations.
| Manufacturer Part Number | 11BG0610A048 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975081617 |
| Alternative Product SKU | BG0610A048 |
| Coil Voltage | 48V |
