11BG0601D060 - MINICONTACTOR 3P BG06.01D 60V
MPN: 11BG0601D060
Alt. SKU: BG0601D060
Special Price
£42.72
£35.60
Regular Price
£71.21
Why Choose the 11BG0601D060?
Engineered for dependable motor switching, the Lovato BG06 three-pole contactor combines compact size with robust performance. SKU 11BG0601D060 features a 60V DC coil, AC3 6A/2.2 kW rating at 400V, and a built-in 1NC auxiliary with mirror contact function for reliable feedback. Quick to install on screw fixings or 35mm DIN rail, it suits modern control panels and machinery.
Built for demanding panels, it carries Ui 690 V and 6 kV impulse withstand, Ith 16 A, and a mechanical life of 20,000,000 cycles. Operates from -50 to +70 °C (storage -60 to +80 °C) up to 3000 m altitude, pollution degree 3. Compliant with IEC/EN 60947-1/-4-1, UL 60947-1/-4-1, and CSA C22.2 n° 60947-1/-4-1, with 3 HP at 480 V and 0.8 to 1 Nm terminal torque.
Key Benefits
- Reliable AC3 motor control up to 6A, 2.2 kW at 400V.
- 60V DC coil for stable operation in DC control circuits.
- Integrated 1NC auxiliary with mirror contact enhances safety feedback.
- Fast installation via screw mounting or 35mm DIN rail.
- Wide operating temperature range from -50 to +70 °C.
- High mechanical life rated at 20,000,000 switching cycles.
- Rated insulation 690 V and 6 kV impulse withstand capability.
Technical Specification
- Product type designation: BG06
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 16 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 220 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BG06 three-pole contactor, 60V DC coil (SKU 11BG0601D060)
- Integrated 1NC auxiliary contact with mirror contact function
- Manufacturer datasheet (PDF download)
- Protective packaging for transit
Applications
- AC-3 motor control up to 2.2 kW at 400 V
- Control panels and MCCs requiring compact three-pole contactors
- Conveyors, pumps, and fans within 6 A AC-3 rating
- HVAC and building services automation circuits
- General-purpose switching in industrial machinery
Frequently Asked Questions
What is the coil voltage and type?
It has a DC coil rated at 60 V.
Does this contactor include an auxiliary contact?
Yes—one built-in 1NC auxiliary contact with mirror contact function.
How can the contactor be mounted?
It mounts by screw fixing or on a 35 mm DIN rail.
What is the operating temperature range?
Operating range is -50 to +70 °C; storage is -60 to +80 °C.
Which standards does it comply with?
IEC/EN 60947-1/-4-1, UL 60947-1/-4-1, and CSA C22.2 n° 60947-1/-4-1.
Safety note: Install and service only by qualified personnel. De-energise circuits before work, observe rated limits and torque values, and ensure environmental conditions match the specified ratings and standards.
| Manufacturer Part Number | 11BG0601D060 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975082539 |
| Alternative Product SKU | BG0601D060 |
| Coil Voltage | 60V |
