11BG0601A400 - 3P MINICONTACTOR BG06.01A 400V 50-60HZ
MPN: 11BG0601A400
Alt. SKU: BG0601A400
Special Price
£30.10
£25.08
Regular Price
£50.16
Why Choose the 11BG0601A400?
Engineered for reliable control, the Lovato 11BG0601A400 three‑pole contactor delivers 6A AC‑3 (2.2 kW) performance at 400 V with a 400 VAC 50/60 Hz coil. It features a built‑in 1NC auxiliary with mirror contact function for safe feedback. Mount via screws or on a 35 mm DIN rail, suiting compact control panels and OEM builds.
Rated Ui 690 V and Uimp 6 kV, this BG06 series device withstands demanding environments, operating from −50 to +70 °C with a 16 A Ith (AC1). It offers 20,000,000 mechanical cycles and 0.8–1 Nm terminal torque for secure connections. Certified to IEC/EN 60947-1/-4-1, UL and CSA standards, with operation up to 3000 m and pollution degree 3.
Key Benefits
- 6A AC-3 at 400 V, suitable for 2.2 kW motor loads.
- 400 VAC 50/60 Hz coil for flexible control circuit compatibility.
- Built-in 1NC auxiliary with mirror contact for reliable feedback.
- Screw or 35 mm DIN rail mounting for fast installation.
- Wide operating temperature range from -50 to +70 °C.
- High insulation ratings: Ui 690 V and Uimp 6 kV.
- Long mechanical life rated to 20,000,000 operations.
Technical Specification
- Product type designation: BG06
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 16 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 178 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BG06 three-pole contactor (SKU 11BG0601A400)
- Built-in 1NC auxiliary contact with mirror contact function
- Manufacturer datasheet (downloadable)
- Protective packaging
Applications
- Small motor control up to 2.2 kW at 400 V (AC-3)
- Power switching in industrial control and automation panels
- OEM machinery control circuits requiring 400 VAC coils
- Distribution boards requiring reliable contactor performance
- General-purpose switching for pumps, fans and conveyors
Frequently Asked Questions
What is the coil voltage and frequency for this contactor?
It has a 400 VAC coil rated for 50/60 Hz operation.
Does the 11BG0601A400 include an auxiliary contact?
Yes, it includes a built-in 1NC auxiliary with mirror contact function.
How can this contactor be mounted?
It can be mounted with screws or on a 35 mm DIN rail.
What are the key current ratings?
It is rated 6A AC-3 at 400 V (2.2 kW) and 16 A Ith (AC1).
Which standards does it conform to?
It conforms to IEC/EN 60947-1/-4-1, UL 60947-1/-4-1 and CSA equivalents.
Safety note: Install and commission only by qualified personnel. Isolate power before work, observe the 0.8–1 Nm terminal torque and all stated voltage, current and environmental ratings.
| Manufacturer Part Number | 11BG0601A400 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975080320 |
| Alternative Product SKU | BG0601A400 |
| Coil Voltage | 400V |
