11BG0601A110 - 3P MINICONTACTOR BG06.01A 110V 50-60HZ
MPN: 11BG0601A110
Alt. SKU: BG0601A110
Special Price
£30.10
£25.08
Regular Price
£50.16
Why Choose the 11BG0601A110?
Optimise compact motor control with the Lovato BG06 three-pole contactor, SKU 11BG0601A110. Featuring a 110VAC coil (50/60Hz) and a built-in 1NC auxiliary with mirror contact function, it delivers reliable switching for AC-3 loads up to 6A/2.2kW at 400V and AC-1 up to 16A. Quick screw or 35mm DIN rail mounting simplifies panel integration and upgrades.
Built for demanding environments, the BG06 offers 690 V rated insulation, 6 kV impulse withstand, and a mechanical life of 20,000,000 cycles. Operates from -50 to +70 °C, stores from -60 to +80 °C, and functions up to 3000 m altitude, pollution degree 3. Compliant with IEC/EN 60947-1/-4-1 and UL/CSA standards, supporting sustainability goals.
Key Benefits
- AC-3 switching to 6A/2.2kW at 400 V for small motors
- AC-1 thermal current rating of 16 A
- 110 VAC coil, 50/60 Hz, for versatile control circuits
- 1NC auxiliary with mirror contact improves reliable feedback
- Ui 690 V and Uimp 6 kV provide strong insulation margins
- Wide operating temperature range of -50 to +70 °C
- Screw or 35 mm DIN rail mounting speeds installation
- Mechanical life rated at 20,000,000 cycles
Technical Specification
- Product type designation: BG06
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 16 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 178 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato BG06 three-pole contactor (SKU 11BG0601A110)
- Integrated 1NC auxiliary contact with mirror contact function
- 35 mm DIN rail/screw mounting-ready housing
- Downloadable manufacturer data sheet
Applications
- Motor starters up to AC-3 6A/2.2kW at 400 V
- General-purpose load switching to 16 A AC-1
- Panel and machine control on 35 mm DIN rail
- HVAC fans and pumps up to 3 HP at 480 V (UL/CSA)
- Automation systems requiring reliable 1NC mirror feedback
Frequently Asked Questions
What coil voltage and frequency does this contactor use?
It has an AC coil rated 110 V for 50/60 Hz operation.
What auxiliary contact is included?
One built-in 1NC auxiliary with mirror contact function is provided.
What are the AC-3 and AC-1 ratings?
AC-3 is 6A/2.2kW at 400 V; AC-1 (Ith) is 16 A.
How can it be mounted in a panel?
It mounts by screws or on a 35 mm DIN rail.
Which standards does it conform to?
It conforms to IEC/EN 60947-1 and 60947-4-1, plus UL and CSA equivalents.
Safety note: Install and commission only by qualified personnel. Verify the 110 VAC coil supply, observe the stated current and environmental ratings, and follow the manufacturer’s instructions and applicable standards.
| Manufacturer Part Number | 11BG0601A110 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975080214 |
| Alternative Product SKU | BG0601A110 |
| Coil Voltage | 110V |
