11BG0031L024 - MINICONTACTOR BG0031L 024V DC
MPN: 11BG0031L024
Alt. SKU: BG0031L024
Special Price
£32.57
£27.14
Regular Price
£54.28
Why Choose the 11BG0031L024?
Lovato’s 11BG0031L024 is a control relay with AC and DC control circuit, engineered for reliable signal switching in industrial panels. It features a low-consumption 24V DC coil and a 4-pole, 3NO+1NC auxiliary contact set for flexible control logic. Mounting is straightforward via screw terminals or 35 mm DIN rail. Rated Ui 690 V with 6 kV impulse withstand, it suits demanding environments.
Built on the BG00 platform, this relay delivers a robust 10 A Ith (IEC) and a mechanical life of 20000000 cycles. Operating temperature spans -50 to +70 °C, with storage to -60 to +80 °C and use up to 3000 m altitude, pollution degree 3. Compliance includes IEC/EN 60947-1 and 60947-5-1 plus UL and CSA equivalents, supporting global panel standards.
Key Benefits
- Low-consumption 24V DC coil reduces control power demand.
- 4-pole, 3NO+1NC contacts for flexible control logic.
- High insulation rating: Ui 690 V, Uimp 6 kV.
- Robust 10 A Ith (IEC) current-carrying capability.
- Wide operating temperature range from -50 to +70 °C.
- Simple screw or 35 mm DIN rail mounting.
- Long mechanical life rated at 20000000 cycles.
Technical Specification
- Product type designation: BG00
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 10 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 203 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato 11BG0031L024 control relay unit
- Manufacturer documentation (datasheet)
- Original packaging
Applications
- Industrial control panels and automation cabinets
- PLC interface and signalling circuits
- Auxiliary control and interlocking in machinery
- General-purpose relay logic for AC/DC control circuits
Frequently Asked Questions
What is the contact configuration?
It provides four poles with 3 normally open and 1 normally closed auxiliary contacts (3NO+1NC).
What coil voltage does it require?
The low-consumption coil is rated at 24 V DC.
How can it be mounted in a panel?
It supports screw mounting or 35 mm DIN rail installation.
What ratings indicate its insulation strength?
It has a rated insulation voltage Ui of 690 V and an impulse withstand voltage Uimp of 6 kV.
What environmental and durability ratings does it have?
Operating temperature is -50 to +70 °C with mechanical life of 20000000 cycles.
Safety note: Installation should be performed by a competent person. De-energise circuits before work, apply 0.8 to 1 Nm terminal torque, and operate within specified temperature and altitude in accordance with IEC/EN 60947.
| Manufacturer Part Number | 11BG0031L024 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975081211 |
| Alternative Product SKU | BG0031L024 |
| Coil Voltage | 24V |
