03238 Wohner fuse link 250 A
MPN: 03238
Alt. SKU: 03238000
Special Price
£393.77
£328.14
Regular Price
£492.20
Why Choose the Eaton Fuse Link 250 A (03238)?
The Eaton fuse link 250 A (part number 03238) is a high-quality, reliable electrical protection component designed for demanding industrial applications. With a rated current of 250 A and voltage ratings up to 600 V AC and 300 V DC, this time delay fuse link ensures optimal protection for your electrical circuits. Manufactured with durable porcelain material and halogen-free construction, it meets stringent safety and environmental standards. Its Class J rating and comprehensive UL and CSA approvals guarantee compatibility and safety in North American and international markets.
Key Benefits
- High Current Capacity: Rated for 250 A, suitable for robust electrical systems.
- Wide Voltage Range: Supports up to 600 V AC and 300 V DC, providing versatile application options.
- Time Delay Operation: Allows temporary overloads without nuisance blowing, enhancing system reliability.
- Durable Porcelain Construction: Ensures mechanical strength and electrical insulation; note this component does not carry current mechanically.
- Halogen-Free: Environmentally friendly design reduces toxic emissions in case of fire.
- Comprehensive Approvals: Certified to UL 248-8, UL 248-1, CSA standards, ensuring safety and compliance.
- Compact Dimensions: 54 x 181 x 54 mm size fits easily into standard fuse holders.
Technical Specifications
- Item number: 03238
- Description: fuse link 250 A
- Rated current: 250 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 54 x 181 x 54 mm
- Weight: 67.0 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: LPJ
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What type of fuse is the Eaton 03238?
It is a Class J time delay fuse link rated at 250 A, designed for protecting electrical circuits against overloads and short circuits.
Can this fuse link be used for DC applications?
Yes, it is rated for use up to 300 V DC, making it suitable for both AC and DC systems.
Is this fuse link environmentally friendly?
Yes, it is halogen free, reducing harmful emissions in the event of a fire.
Does the fuse link carry current mechanically?
No, as a mechanical component, the fuse link does not carry current; it functions as a protective device within the electrical circuit.
Where can I find technical documentation for this product?
Technical documents such as general technical information, characteristics, and EU declaration of conformity are available via the manufacturer's website.
| Manufacturer Part Number | 03238 |
|---|---|
| Barcode | 4021267032388 |
| Height | 181mm |
| Width | 54mm |
| Depth | 54mm |
| Country of Manufacture | Mexico |
| HS Code | 85361090 |
| Alternative Product SKU | 03238000 |
| Manufacturer | Wohner |
| Packed Quantity | 1 |
| Utilization category according to IEC 60269 | Other |
| Release characteristic | J |
