03234 Wohner fuse link 150 A
MPN: 03234
Alt. SKU: 03234000
Special Price
£189.12
£157.60
Regular Price
£236.40
Why Choose the Eaton Fuse Link 150 A (03234)?
The Eaton fuse link 150 A (Part No.: 03234) is a reliable and robust electrical protection device designed for high-performance applications. With a time delay operation and Class J rating, it ensures effective protection of electrical circuits against overloads and short circuits. Its porcelain construction guarantees durability and safety, while its halogen-free design supports environmentally conscious installations. Certified to rigorous UL and CSA standards, this fuse link offers peace of mind and compliance for your electrical systems.
Key Benefits
- High Current Rating: Supports up to 150 A, suitable for demanding electrical circuits.
- Wide Voltage Compatibility: Rated for 600 V AC and 300 V DC, accommodating various power systems.
- Time Delay Operation: Allows temporary current surges without nuisance blowing, ideal for motor and transformer protection.
- Durable Porcelain Material: Ensures mechanical strength and electrical insulation.
- Halogen-Free: Environmentally friendly and safer in case of fire.
- Certified Safety Standards: UL 248-8, UL 248-1, and CSA approvals guarantee compliance and reliability.
- Compact Dimensions: 41 x 146 x 41 mm for easy integration into existing fuse holders.
Technical Specifications
- Item number: 03234
- Description: fuse link 150 A
- Rated current: 150 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 41 x 146 x 41 mm
- Weight: 35.5 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: LPJ
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the purpose of the Eaton fuse link 150 A?
This fuse link is designed to protect electrical circuits by interrupting current flow during overloads or short circuits, preventing damage to equipment.
Does this fuse link carry current continuously?
As a mechanical fuse link, it does not carry current continuously but interrupts current flow when a fault condition occurs.
What does time delay operation mean?
Time delay operation allows the fuse to tolerate temporary current surges without blowing, which is useful for protecting motors and transformers.
Is this fuse link environmentally friendly?
Yes, it is halogen-free, reducing harmful emissions in case of fire and supporting safer disposal.
What certifications does this fuse link have?
It is certified under UL 248-8, UL 248-1, and CSA standards, ensuring compliance with North American safety requirements.
| Manufacturer Part Number | 03234 |
|---|---|
| Barcode | 4021267032340 |
| Height | 146mm |
| Width | 41mm |
| Depth | 41mm |
| Country of Manufacture | Mexico |
| HS Code | 85361090 |
| Alternative Product SKU | 03234000 |
| Manufacturer | Wohner |
| Packed Quantity | 1 |
| Utilization category according to IEC 60269 | Other |
| Release characteristic | J |
