03229 Wohner fuse link 80 A
MPN: 03229
Alt. SKU: 03229000
Special Price
£94.50
£78.75
Regular Price
£118.13
Why Choose the Eaton Fuse Link 80 A (03229)?
The Eaton fuse link 80 A (part number 03229) is a reliable and robust electrical protection component designed to safeguard your electrical circuits. Featuring a time delay operation and Class J rating, it is ideal for applications requiring high interrupting capacity and dependable performance. Manufactured with high-quality porcelain material, this fuse link is halogen free and meets stringent safety standards, including UL and CSA approvals.
Key Benefits
- High Interrupting Capacity: Rated for 200 kA AC and 100 kA DC, ensuring superior protection against short circuits.
- Time Delay Operation: Allows temporary overloads without nuisance blowing, suitable for motor and transformer protection.
- Durable Construction: Made from porcelain, providing excellent insulation and mechanical strength.
- Wide Voltage Compatibility: Suitable for use up to 600 V AC and 300 V DC systems.
- Safety Certified: Complies with UL 248-8, UL 248-1, and CSA standards for assured quality and safety.
- Environmentally Friendly: Halogen free material reduces environmental impact.
Technical Specifications
- Item number: 03229
- Description: fuse link 80 A
- Rated current: 80 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 29 x 117 x 29 mm
- Weight: 14.5 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: LPJ
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the primary function of this fuse link?
This fuse link provides overcurrent protection for electrical circuits, preventing damage from short circuits and overloads.
Can this fuse link be used in both AC and DC circuits?
Yes, it is rated for use in AC circuits up to 600 V and DC circuits up to 300 V.
Is the fuse link suitable for motor protection?
Yes, its time delay operation allows it to handle temporary overloads common in motor start-up conditions.
Does this fuse link carry current?
Yes, as an electrical fuse link, it carries current and interrupts the circuit when necessary to protect equipment.
Is the fuse link environmentally friendly?
Yes, it is made from halogen free materials, reducing environmental impact.
| Manufacturer Part Number | 03229 |
|---|---|
| Barcode | 4021267032296 |
| Height | 117mm |
| Width | 29mm |
| Depth | 29mm |
| Country of Manufacture | Mexico |
| HS Code | 85361090 |
| Alternative Product SKU | 03229000 |
| Manufacturer | Wohner |
| Packed Quantity | 5 |
| Utilization category according to IEC 60269 | Other |
| Release characteristic | J |
