03226 Wohner fuse link 350 A
MPN: 03226
Alt. SKU: 03226000A
Special Price
£361.22
£301.02
Regular Price
£451.54
Why Choose the Eaton Fuse Link 350 A (03226)?
The Eaton fuse link 350 A (Part No. 03226) is a high-quality, fast-acting protective device designed for industrial electrical applications. Rated at 350 A and 600 V AC, it ensures reliable circuit protection with a Class J rating, suitable for demanding environments. Manufactured with durable porcelain material and halogen-free components, this fuse link combines safety, performance, and environmental responsibility.
Key Benefits
- Fast Acting Protection: Quickly interrupts fault currents to protect sensitive equipment and minimise downtime.
- High Interrupting Capacity: Rated for a short-circuit current rating (SCCR) of 200 kA AC, providing robust protection in high fault current scenarios.
- Reliable and Durable: Constructed from high-quality porcelain, ensuring mechanical strength and longevity.
- Compliance and Safety: Certified to UL 248-8, UL 248-1, and CSA standards, meeting stringent safety and performance requirements.
- Environmentally Friendly: Halogen-free design reduces environmental impact and enhances safety in case of fire.
- Standard Dimensions: Compact size (54 x 181 x 54 mm) fits easily into existing fuse holders and switchgear.
Technical Specifications
- Item number: 03226
- Description: fuse link 350 A
- Rated current: 350 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 54 x 181 x 54 mm
- Weight: 67.0 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: JKS
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the primary function of this fuse link?
This fuse link provides overcurrent protection by interrupting excessive current flow to prevent damage to electrical circuits and equipment.
Is this fuse link suitable for DC applications?
No, this fuse link is rated for AC voltage up to 600 V and is not specified for DC applications.
Does the fuse link carry current mechanically?
The fuse link is an electrical protective device and does not carry current mechanically; it interrupts current flow when necessary.
What approvals does this fuse link have?
It is approved under UL 248-8, UL 248-1, CSA, and carries type number JKS with UL and CSA file certifications.
Where can I find technical documentation for this product?
Technical information, characteristics, and EU declaration of conformity can be downloaded from the manufacturer's website.
| Manufacturer Part Number | 03226 |
|---|---|
| Barcode | 4021267032265 |
| Height | 181mm |
| Width | 54mm |
| Depth | 54mm |
| Country of Manufacture | Mexico |
| HS Code | 85361010 |
| Alternative Product SKU | 03226000A |
| Manufacturer | Wohner |
| Packed Quantity | 1 |
| Utilization category according to IEC 60269 | Other |
| Release characteristic | J |
