03221 Wohner fuse link 175 A
MPN: 03221
Alt. SKU: 03221000
Special Price
£214.18
£178.48
Regular Price
£267.72
Fuse Link 175 A (03221) by Mersen
Experience reliable overcurrent protection with the Mersen fuse link 175 A, designed for fast acting performance in demanding electrical applications. This Class J fuse link is engineered to safeguard your systems up to 600 V AC and 300 V DC, ensuring safety and compliance with international standards.
Why Choose the Mersen Fuse Link 175 A?
- High Performance: Fast acting design provides rapid response to overcurrent conditions, minimising equipment damage.
- Robust Construction: Made from durable porcelain material that is halogen free, enhancing safety and environmental compliance.
- Wide Application Range: Suitable for use in both AC and DC circuits with rated voltages of 600 V AC and 300 V DC.
- Certified Quality: Holds multiple approvals including UL 248-8, UL 248-1, and CSA, ensuring adherence to stringent safety standards.
- Compact Dimensions: Measures 41 x 146 x 41 mm, fitting seamlessly into standard fuse holders.
Key Benefits
- Enhanced System Protection: Prevents damage from electrical faults by interrupting excessive currents quickly.
- Reliable Operation: Class J rating ensures consistent performance in industrial and commercial electrical systems.
- Environmentally Friendly: Halogen-free composition reduces harmful emissions in case of fire.
- Easy Integration: Compatible with existing fuse holders and systems thanks to standard dimensions and type number A4J.
- Comprehensive Documentation: Access to detailed technical information and CAD data facilitates installation and maintenance.
Technical Specifications
- Item number: 03221
- Description: fuse link 175 A
- Rated current: 175 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 41 x 146 x 41 mm
- Weight: 38.5 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: A4J
- Approval: UL file: E2137, UL category (for USA): JDDZ_ https://www.ul.com
- Approval: CSA file: 12636, CSA class: 1422-02_ https://directories.csa-international.org
Frequently Asked Questions
What type of fuse is the Mersen 03221?
The Mersen 03221 is a fast acting Class J fuse link designed for overcurrent protection in electrical circuits.
Can this fuse link be used in DC applications?
Yes, it is rated for use up to 300 V DC, making it suitable for both AC and DC electrical systems.
Is the fuse link environmentally friendly?
Yes, it is made from halogen-free porcelain, reducing harmful emissions in case of fire.
Does this fuse link carry current?
Yes, as an electrical fuse link, it carries current under normal operating conditions and interrupts current during faults.
Where can I find technical documentation and CAD data?
Technical information and CAD data are available via the provided download links from the manufacturer.
| Manufacturer Part Number | 03221 |
|---|---|
| Barcode | 4021267032210 |
| Height | 146mm |
| Width | 41mm |
| Depth | 41mm |
| Country of Manufacture | Mexico |
| HS Code | 85361010 |
| Alternative Product SKU | 03221000 |
| Manufacturer | Wohner |
| Packed Quantity | 1 |
| Utilization category according to IEC 60269 | Other |
| Release characteristic | J |
