03219 Wohner fuse link 125 A
MPN: 03219
Alt. SKU: 03219000A
Special Price
£144.07
£120.06
Regular Price
£180.08
Why Choose the Mersen Fuse Link 125 A (03219)?
The Mersen fuse link 125 A (part number 03219) is a reliable and fast-acting electrical protection device designed for industrial applications. Rated for 600 V AC and 300 V DC, this Class J fuse link ensures superior circuit protection with a high interrupting rating, making it suitable for demanding electrical environments. Its robust porcelain construction is halogen free, promoting safety and environmental responsibility.
Key Benefits
- Fast acting operation for quick circuit interruption, minimising damage.
- High rated current of 125 A suitable for a wide range of industrial electrical systems.
- Compatible with both AC (600 V) and DC (300 V) applications.
- Porcelain material ensures excellent insulation and durability.
- Halogen free design supports safer and more environmentally friendly installations.
- Certified to multiple standards including UL 248-8, UL 248-1, and CSA for assured quality and compliance.
- Compact dimensions (41 x 146 x 41 mm) for easy integration into existing systems.
Technical Specifications
- Item number: 03219
- Description: fuse link 125 A
- Rated current: 125 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 41 x 146 x 41 mm
- Weight: 38.5 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: A4J
- Approval: UL file: E2137, UL category (for USA): JDDZ_ https://www.ul.com
- Approval: CSA file: 12636, CSA class: 1422-02_ https://directories.csa-international.org
Frequently Asked Questions
What type of protection does this fuse link provide?
This fuse link provides overcurrent protection by interrupting excessive current flow to prevent damage to electrical circuits and equipment.
Is this fuse link suitable for DC applications?
Yes, it is rated for use up to 300 V DC, making it suitable for both AC and DC circuits.
Does the fuse link carry current?
Yes, as an electrical fuse link, it carries current under normal operating conditions and interrupts current flow when an overcurrent condition occurs.
What does 'fast acting' mean?
'Fast acting' indicates the fuse link will quickly interrupt current flow in the event of a fault, providing rapid protection to the circuit.
Is the fuse link environmentally friendly?
Yes, it is halogen free, reducing harmful emissions in case of fire and supporting safer disposal.
| Manufacturer Part Number | 03219 |
|---|---|
| Barcode | 4021267032197 |
| Height | 146mm |
| Width | 41mm |
| Depth | 41mm |
| Country of Manufacture | Mexico |
| HS Code | 85361010 |
| Alternative Product SKU | 03219000A |
| Manufacturer | Wohner |
| Packed Quantity | 1 |
| Utilization category according to IEC 60269 | Other |
| Release characteristic | J |
